Siemens 3SE5 Series Safety Enabling Switch, 5 Position, 1 NO/2 NC, IP65, IP67
- RS 제품 번호:
- 153-281
- 제조사 부품 번호:
- 3SE5312-0SG12
- 제조업체:
- Siemens
Subtotal (1 unit)*
₩1,855,540.00
제조사가 재고 비축중
- 2026년 10월 09일 부터 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩1,855,540.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 153-281
- 제조사 부품 번호:
- 3SE5312-0SG12
- 제조업체:
- Siemens
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Siemens | |
| Series | 3SE5 | |
| Product Type | Safety Enabling Switch | |
| Contact Configuration | 1 NO/2 NC | |
| Number of Positions | 5 | |
| IP Rating | IP65, IP67 | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Housing Material | Metal | |
| Contact Voltage | 250V | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | UKCA, CCC, TUV, EAC, CE, cULus | |
| Hazardous Area Certification | No | |
| Depth | 43.8mm | |
| Mechanical Life | 1000000Cycles | |
| Width | 54mm | |
| Length | 185mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Siemens | ||
Series 3SE5 | ||
Product Type Safety Enabling Switch | ||
Contact Configuration 1 NO/2 NC | ||
Number of Positions 5 | ||
IP Rating IP65, IP67 | ||
Terminal Type Screw | ||
Minimum Operating Temperature -25°C | ||
Housing Material Metal | ||
Contact Voltage 250V | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals UKCA, CCC, TUV, EAC, CE, cULus | ||
Hazardous Area Certification No | ||
Depth 43.8mm | ||
Mechanical Life 1000000Cycles | ||
Width 54mm | ||
Length 185mm | ||
- COO (Country of Origin):
- DE
The Siemens Safety Position Switch with tumbler design ensures unparalleled protection in industrial environments. Engineered for five directions of approach, it is equipped with a powerful locking force of up to 2600 N, making it ideal for complex safety requirements. The device features a robust metal enclosure, designed for resilience and durability, providing remarkable resistance to environmental conditions with an IP65/IP67 protection class. Spring actuated locks and dual release mechanisms enhance operational safety while allowing for simple installation and maintenance. The product is not only versatile but also prioritises user safety and compliance with strict standards.
Robust design facilitates longevity even in challenging conditions
Metal enclosure provides durability against physical and environmental stress
Spring actuated locking mechanism enhances operational reliability
User friendly installation process reduces downtime in operations
Compliance with EN ISO 14119 standards increases safety assurance
Low power consumption for energy efficient operation
