Siemens 3SE5 Series Safety Enabling Switch, 5 Position, 1 NO/2 NC, IP65
- RS 제품 번호:
- 153-096
- 제조사 부품 번호:
- 3SE5232-1QV40
- 제조업체:
- Siemens
Subtotal (1 unit)*
₩298,837.50
현재 액세스할 수 없는 재고 정보 - 나중에 다시 확인해 주세요.
수량 | 한팩당 |
|---|---|
| 1 + | ₩298,837.50 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 153-096
- 제조사 부품 번호:
- 3SE5232-1QV40
- 제조업체:
- Siemens
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Siemens | |
| Product Type | Safety Enabling Switch | |
| Series | 3SE5 | |
| Contact Configuration | 1 NO/2 NC | |
| Number of Positions | 5 | |
| IP Rating | IP65 | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Housing Material | Plastic | |
| Contact Voltage | 400V | |
| Maximum Operating Temperature | 60°C | |
| Hazardous Area Certification | NO | |
| Standards/Approvals | TUV, cULus, UKCA, CCC, CE, EAC | |
| Depth | 32.7mm | |
| Mechanical Life | 1000000Cycles | |
| Width | 31mm | |
| Length | 104mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Siemens | ||
Product Type Safety Enabling Switch | ||
Series 3SE5 | ||
Contact Configuration 1 NO/2 NC | ||
Number of Positions 5 | ||
IP Rating IP65 | ||
Terminal Type Screw | ||
Minimum Operating Temperature -25°C | ||
Housing Material Plastic | ||
Contact Voltage 400V | ||
Maximum Operating Temperature 60°C | ||
Hazardous Area Certification NO | ||
Standards/Approvals TUV, cULus, UKCA, CCC, CE, EAC | ||
Depth 32.7mm | ||
Mechanical Life 1000000Cycles | ||
Width 31mm | ||
Length 104mm | ||
The Siemens Safety Position Switch offers a robust plastic enclosure and an array of advanced features to ensure maximum operational safety in various applications. Designed for reliable performance, it boasts slow action contacts and multiple directions of approach, making it versatile in its use. With an impressive mechanical service life of up to one million cycles, this device enhances productivity while minimizing downtime. Its compact design allows for easy installation, and the protection class rating of IP65 ensures it is dust tight and resistant to water ingress. Combining high endurance with top tier safety standards, this switch is an excellent choice for those seeking reliability in demanding environments.
Incorporates positive opening technology for enhanced safety mechanisms
Provides excellent insulation voltage ratings for added reliability
Maintains operational integrity over a wide temperature range from 25 to +85 °C
Complies with international standards for safety and operational excellence
