Insulation Testers

Insulation testers are electrical measurement test tools used for preventative or predictive maintenance programs. Also known as megohmmeters they are designed to identify potential equipment failures before they occur. Insulation resistance testers are perfect for testing a wide range of high voltage equipment including switchgear, motors, generators and cables.

RS Components offer a range of high-quality electrical test tools from leading brands including Megger, Fluke, Chauvin Arnoux, Keysight Technologies, Metrohm, FLIR and of course RS PRO.

We also offer an in-house calibration service. See here for more details calibration services

Insulation tester types

Insulation testers are handheld devices but can be portable with a handle or bench mounted. Testers usually have an LCD or digital display, but some have the more traditional analogue needle such as the Megger MIT310A.

How do insulation resistance testers work?

Testing the integrity of insulation requires measuring its resistance to current flow across it. Testers use high voltage low current DC charge to measure the resistance. A high level of resistance means that very little current is escaping through the insulation. Conversely, a low level of resistance indicates a significant amount of current may be leaking through and along the insulation.

What is the purpose of insulation testing?

Ideally, all the electrical current sent along a conductive wire should reach its intended destination. However, you do find that some of it is lost along the way due to various reasons. Wires are insulated with a resistant sheathing to contain the conductivity of the copper or aluminium core, but even with this insulation in place, some of the current still manages to escape. The electricity that leaks out can be detrimental to electrical circuits and machinery.

Testing can help you determine whether the insulation is performing at an effective and safe level. Excessive heat or cold, moisture, vibration, dirt, oil and corrosive vapours can all contribute to deterioration therefore routine testing can identify problems before they result in injury or equipment failure.

Insulation testers provide noise-free, reliable results. They are safe and easy to use and the ideal solution for troubleshooting, commissioning and preventative maintenance applications.


...
Read more Read less

검색 필터링

총 101개 제품 중 61번째-80번째 제품을 조회 중
한장내 검색 결과 수
제품설명 단가 Tester Type Minimum Test Voltage Maximum Test Voltage Maximum Insulation Resistance Measurement Display Type Test Current Battery Life Minimum Operating Temperature Maximum Operating Temperature Power Source Safety Category Level Safety Category Voltage Safety Category Battery Type
RS 제품 번호 123-1931
제조사RS PRO
₩250,179.30
Each
수량
Insulation Tester 250V 1000V 2GΩ LCD ≤200mA - 0°C +40°C Battery CAT III 1000V CAT III 1000V AA
RS 제품 번호 917-6298
제조사RS PRO
₩1,815,556.85
Each
수량
Dielectric Strength Tester 50V 1000V 9.5GΩ LCD - Dot Matrix - - 0°C +40°C Mains - - - -
RS 제품 번호 123-1934
제조사RS PRO
₩268,593.30
Each
수량
Insulation Tester 125V 1000V 4GΩ LCD 1mA - 0°C +40°C Battery CAT III 1000V CAT III 1000V AA
RS 제품 번호 122-6797
제조사 부품 번호1004-742
제조사Megger
₩1,492,840.65
Each
수량
Insulation Tester 50V 500V 200GΩ Digital 20 mA @ 10.0 Ω → 99.9 Ω, 205 mA @ 0.01 Ω → 9.99 Ω 2200 5-Second Tests -20°C +55°C Battery CAT IV 600V CAT IV 600V Alkaline, NiMH
RS 제품 번호 161-1630
제조사RS PRO
₩295,709.00
Each
수량
Insulation Tester 125V 1000V 4GΩ LCD 1mA - +5°C +40°C Battery - 600 V, 1000 V CAT III 1000 V, CAT IV 600V 1.5 V AAA, 9V NEDA 1604
RS 제품 번호 187-9915
제조사 부품 번호47339611
제조사Socomec
₩3,038,509.95
Each
수량
Insulation Tester - - - LCD - - -10°C +55°C - - - - -
RS 제품 번호 921-4514
제조사 부품 번호1004-735
제조사Megger
₩925,401.15
Each
수량
Insulation Tester 10V 1000V 200GΩ Analogue, Dual Digital 205mA 2200 (OFF) Test @ 55 s, 2200 (ON) Test @ 5 s -20°C +55°C Battery CAT IV 600V CAT IV 600V Alkaline
RS 제품 번호 175-7819
제조사 부품 번호FLUKE-1555 FC Kit w/IR3000
제조사Fluke
₩7,663,249.60
Each
수량
Insulation Tester 250V 10000V 2TΩ LCD 1 nA → 2 mA 750 Tests -20°C +50°C Battery CAT III, CAT IV 600 V, 1000 V CAT III 1000 V, CAT IV 600V Rechargeable Lead Acid (Yuasa NP2.8-12)
RS 제품 번호 175-7822
제조사 부품 번호FLUKE-1550C FC Kit w/IR3000
제조사Fluke
₩7,015,413.15
Each
수량
Insulation Tester 250V 5000V 1TΩ LCD 1 nA → 2 mA 750 Tests -20°C +50°C Battery CAT III, CAT IV 600 V, 1000 V CAT III 1000 V, CAT IV 600V Rechargeable Lead Acid (Yuasa NP2.8-12)
RS 제품 번호 123-2237
제조사RS PRO
₩344,687.45
Each
수량
Insulation Tester 250V 1000V 4GΩ LCD 1mA - 0°C +40°C Battery - - - AA
RS 제품 번호 201-0448
제조사RS PRO
₩2,709,646.45
Each
수량
Insulation Tester 50V 1200V - TFT LCD 40 mA AC / 10 mA DC 2 Years 0°C 40°C Mains CAT I - CAT I CR0232
RS 제품 번호 914-2875
제조사 부품 번호P01140822
제조사Chauvin Arnoux
₩785,953.85
Each
수량
Insulation & Continuity Tester 250V 1000V 40GΩ Backlit Digital LCD, Backlit LCD 200mA 1500 Measurements, 3000 Measurements -20°C +55°C Battery CAT IV 600V CAT IV 600V AA
신제품
RS 제품 번호 212-5537
제조사 부품 번호P01140838
제조사Chauvin Arnoux
₩591,129.70
Each
수량
Insulation & Continuity Tester 0V 700V - LCD - - - - - - - CAT IV 600 V -
RS 제품 번호 201-0450
제조사RS PRO
₩5,034,347.30
Each
수량
Insulation Tester 50V 1200V 50GΩ TFT LCD 40 mA AC / 10 mA DC / 10 mA IR / 32 A GB 2 Years 0°C 40°C Mains CAT I - CAT I CR2032
RS 제품 번호 914-2879
제조사 부품 번호P01140824
제조사Chauvin Arnoux
₩894,188.80
Each
수량
Insulation & Continuity Tester 50V 1000V 200GΩ Backlit Digital LCD, Backlit LCD 200mA 1500 Measurements, 3000 Measurements -20°C +55°C Battery CAT IV 600V CAT IV 600V AA
RS 제품 번호 189-1913
제조사 부품 번호1002-907
제조사Megger
₩7,655,166.35
Each
수량
Insulation Tester 1000V 15000V 30TΩ Backlit LCD 3mA 4.5 h -20°C +50°C Battery, Mains CAT IV 1000V CAT IV 1000V Li-Ion
RS 제품 번호 917-6294
제조사RS PRO
₩6,928,021.05
Each
수량
Insulation Tester 50V 1000V 50GΩ LCD - Dot Matrix - - 0°C +40°C Mains - - - -
RS 제품 번호 917-6308
제조사RS PRO
₩3,682,341.20
Each
수량
Insulation Tester 50V 1000V 9.5GΩ LCD - Dot Matrix - - 0°C +40°C Mains - - - -
RS 제품 번호 719-0914
제조사 부품 번호450A922
제조사Seaward Clare
₩8,442,532.25
Each
수량
Flash Tester 250V 5000 V ac, 6000V dc 999.9MΩ LCD 0.1 → 40A - - - Mains - - - -
RS 제품 번호 820-2973
제조사 부품 번호U1453A
₩1,626,163.90
Each
수량
Insulation Tester 50V 1000V 260GΩ LCD 1mA 160 h -40°C +55°C Battery CAT III, CAT IV 600 V, 1000 V CAT III 1000 V, CAT IV 600V AA
