Siretta SENTRY-G-LTE4 (EU) RF Detector 2.6 GHz USB Mini-B, SMA Connector

RS 제품 번호:: 272-8578
제조사 부품 번호:: SENTRY-G-LTE4 (EU)
제조업체:: Siretta

Siretta SENTRY-G-LTE4 (EU) RF Detector 2.6 GHz USB Mini-B, SMA Connector

대량 구매 할인 기용 가능

View bulk pricing options

Subtotal (1 unit)*

₩786,900.00

일시적 품절

2027년 6월 23일 부터 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 - 4	₩786,900.00
5 - 9	₩767,100.00
10 +	₩747,160.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 272-8578
제조사 부품 번호:: SENTRY-G-LTE4 (EU)
제조업체:: Siretta

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Siretta
	Maximum Frequency	2.6GHz
	Product Type	RF Detector
	Minimum Frequency	700MHz
	Connector Type	USB Mini-B, SMA Connector
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Weight	100g
	Standards/Approvals	CE, E11 (TBC), REACH, FCC (TBC), UKCA, RoHS

	모두 선택
	브랜드 Siretta
	Maximum Frequency 2.6GHz
	Product Type RF Detector
	Minimum Frequency 700MHz
	Connector Type USB Mini-B, SMA Connector
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Weight 100g
	Standards/Approvals CE, E11 (TBC), REACH, FCC (TBC), UKCA, RoHS

COO (Country of Origin):: GB

Siretta RF Detector, 700MHz Minimum Frequency, 2.60GHz Maximum Frequency - SENTRY-G-LTE4 (EU)

This Siretta SENTRY-G-LTE4 (EU) handheld device detects radio-frequency signals across mobile and wireless bands for field diagnostics and testing. It connects via USB Mini-B for power or data and accepts external antennas through an SMA interface. The instrument is Compact and lightweight for carried inspections and is specified to operate across a wide ambient temperature range, making it suitable for deployments in varied environmental conditions.

Features and Benefits:

• 700 MHz minimum frequency for mobile band coverage
• 2.60 GHz maximum frequency for wideband detection
• USB Mini‑B connector for straightforward power/data connection
• SMA connector for compatibility with test antennas
• Operates between -40 and 85 °C for harsh environments

Applications

• Suitable for detecting mobile network interference
• Used for site verification during RF installations
• Ideal for portable signal surveys and diagnostics
• Can be used for troubleshooting antenna systems
• Used with external antennas for targeted measurements

What are the physical dimensions of the unit?

The enclosure measures 67 mm height, 28 mm width, and 93 mm length.

How heavy is the detector for handheld use?

It weighs 100 g, facilitating extended handheld inspections.

Which standards and approvals does it carry?

It holds CE, RoHS and UKCA listings and is noted as REACH and FCC status pending.

What connector types are provided for interfacing?

A USB Mini‑B port is provided alongside an SMA connector for antenna connection.
