Siemens 1A SIRIUS 3RV2 Motor Protection Circuit Breaker, 20V, 690 V, 60 °C, -20 °C

RS 제품 번호:: 160-246
제조사 부품 번호:: 3RV2021-0JA25
제조업체:: Siemens

Siemens 1A SIRIUS 3RV2 Motor Protection Circuit Breaker, 20V, 690 V, 60 °C, -20 °C

Subtotal (1 unit)*

₩511,560.00

제조사가 재고 비축중

2026년 10월 26일 부터 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩511,560.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

Our Better World range features products that make it easy for you to make a greener product choice you can trust.

Learn more about RS Better World products

RS 제품 번호:: 160-246
제조사 부품 번호:: 3RV2021-0JA25
제조업체:: Siemens

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Siemens
	Product Type	Motor Protection Circuit Breaker
	Current Rating	1A
	Motor Protection Component	Circuit Breaker
	Supply Voltage	20V, 690V
	Motor Protection System	3RV2
	Series	SIRIUS 3RV2
	Overall Length	119mm
	Overall Width	45mm
	Overall Depth	97mm
	IP Rating	IP20
	Minimum Operating Temperature	-20°C
	Maximum Operating Temperature	60°C
	Standards/Approvals	ABS, ATEX, CCC, CE, DNV, EAC, EPD, IEC 61508-2, IECEX, ISO 13849-1, ISO 13849-2, LRS, PRS, RINA, RoHS, UKCA, UL, VDE
	Better World Product	Yes
	Number of Poles	3
	Better World Claim	Extended Product Life, Low Carbon Manufacture

	모두 선택
	브랜드 Siemens
	Product Type Motor Protection Circuit Breaker
	Current Rating 1A
	Motor Protection Component Circuit Breaker
	Supply Voltage 20V, 690V
	Motor Protection System 3RV2
	Series SIRIUS 3RV2
	Overall Length 119mm
	Overall Width 45mm
	Overall Depth 97mm
	IP Rating IP20
	Minimum Operating Temperature -20°C
	Maximum Operating Temperature 60°C
	Standards/Approvals ABS, ATEX, CCC, CE, DNV, EAC, EPD, IEC 61508-2, IECEX, ISO 13849-1, ISO 13849-2, LRS, PRS, RINA, RoHS, UKCA, UL, VDE
	Better World Product Yes
	Number of Poles 3
	Better World Claim Extended Product Life, Low Carbon Manufacture

COO (Country of Origin):: DE

The Siemens circuit breaker is expertly designed for motor protection, catering specifically to diverse operational requirements. With its compact S0 size, it offers a robust solution that seamlessly integrates into various systems. The product is equipped with a CLASS 10 thermal overload release, ensuring reliable protection against overheating while maintaining peak performance. It boasts impressive mechanical and electrical endurance, both rated for typical usage up to 100, 000 cycles. Enhanced with precise overload settings, it can respond to overload conditions with accuracy and efficiency. The durable build quality and advanced features make it a preferred choice for professionals seeking reliability and efficiency in motor control applications.

Thermal overload protection with adjustable settings

High electrical and mechanical durability

Includes auxiliary switch capabilities for functionality

Excellent performance across wide temperatures
