Siemens 3SE5 Series Safety Enabling Switch, 5 Position, 1 NO/2 NC, IP67, IP66
- RS 제품 번호:
- 153-203
- 제조사 부품 번호:
- 3SE5322-0SE22
- 제조업체:
- Siemens
Subtotal (1 unit)*
₩1,138,137.00
제조사가 재고 비축중
- 2026년 5월 21일 부터 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩1,138,137.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 153-203
- 제조사 부품 번호:
- 3SE5322-0SE22
- 제조업체:
- Siemens
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Siemens | |
| Product Type | Safety Enabling Switch | |
| Series | 3SE5 | |
| Contact Configuration | 1 NO/2 NC | |
| Number of Positions | 5 | |
| IP Rating | IP67, IP66 | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -25°C | |
| Housing Material | Plastic | |
| Contact Voltage | 250V | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | cULus, TUV, UKCA, CCC, EAC, CE | |
| Hazardous Area Certification | NO | |
| Depth | 43.8mm | |
| Mechanical Life | 1000000Cycles | |
| Width | 54mm | |
| Length | 185mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Siemens | ||
Product Type Safety Enabling Switch | ||
Series 3SE5 | ||
Contact Configuration 1 NO/2 NC | ||
Number of Positions 5 | ||
IP Rating IP67, IP66 | ||
Terminal Type Screw | ||
Minimum Operating Temperature -25°C | ||
Housing Material Plastic | ||
Contact Voltage 250V | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals cULus, TUV, UKCA, CCC, EAC, CE | ||
Hazardous Area Certification NO | ||
Depth 43.8mm | ||
Mechanical Life 1000000Cycles | ||
Width 54mm | ||
Length 185mm | ||
The Siemens mechanical safety switch with tumbler offers robust performance across five directions of approach, ensuring maximum flexibility and adaptability in various applications. Designed for safety and reliability, it features an impressive locking force and a spring-lock mechanism with an auxiliary release. The enclosure is built to endure harsh environments, rated at IP66/IP67 for dust and water resistance, making it an excellent choice for industrial settings. Its high mechanical service life ensures longevity, while the positive opening function adds an extra layer of safety. An array of optional actuators enhances its versatility, allowing it to meet diverse operational needs. Coupled with its advanced technical specifications, this safety switch stands out as a reliable component for any safety-critical application.
Robust plastic enclosure enhances durability and strength
High locking force ensures increased security
Positive opening mechanism enhances user safety
Multiple actuator options for tailored installations
Excellent protection against environmental factors provided
