SMC EX260 series Pneumatic Logic Controller

RS 제품 번호:: 426-824
제조사 부품 번호:: EX260-SDN1
제조업체:: SMC

SMC EX260 series Pneumatic Logic Controller

모든 Pneumatic Logic Controllers 열람하기

Subtotal (1 unit)*

₩715,981.50

제조사가 재고 비축중

2026년 5월 25일 부터 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩715,981.50

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 426-824
제조사 부품 번호:: EX260-SDN1
제조업체:: SMC

사양

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	SMC
	Product Type	Pneumatic Logic Controller
	Number of Inputs	8
	Series	EX260
	Voltage	24V
	Display Type	LED Indicator
	Hazardous Area Certification	NO
	Number of Outputs	32
	Minimum Operating Temperature	-10°C
	Maximum Operating Temperature	+50°C
	Width	28mm
	Height	102mm
	Standards/Approvals	RoHS, UL, CE
	Depth	76.5mm
	Output Type	Digital Output
	Suitable Medias	Air
	Connection Type	M12

	모두 선택
	브랜드 SMC
	Product Type Pneumatic Logic Controller
	Number of Inputs 8
	Series EX260
	Voltage 24V
	Display Type LED Indicator
	Hazardous Area Certification NO
	Number of Outputs 32
	Minimum Operating Temperature -10°C
	Maximum Operating Temperature +50°C
	Width 28mm
	Height 102mm
	Standards/Approvals RoHS, UL, CE
	Depth 76.5mm
	Output Type Digital Output
	Suitable Medias Air
	Connection Type M12

COO (Country of Origin):: JP

SMC EX260 Series Pneumatic Logic Controller, 8 Inputs, 32 Outputs - EX260-SDN1

This pneumatic logic controller is designed to manage pneumatic actuation within industrial Air systems, providing digital control of multiple outputs via an M12 interface. It operates from a 24V supply and uses LED indicators for status monitoring, making it suitable for integration into automation setups that require compact, high-density control of pneumatic devices.

Features & Benefits

• Eight signal inputs enable complex logical sequencing for machines
• Thirty-two digital outputs support high-density device control
• LED indication offers immediate operational status feedback
• M12 connection simplifies field wiring and connector standardisation
• Supports ambient temperatures from -10°C to +50°C for varied environments

Applications

• Suitable for centralised valve control in factory automation
• Ideal for pneumatic tooling stations in manufacturing cells
• Used with compressed-air handling systems for process control
• Can be used for sequencing in material-handling equipment
• Suitable for integration into modular assembly-line controls

What voltage does it require to operate?

It is powered from a 24V supply compatible with typical industrial control networks.

How does the unit indicate valve or logic status?

Integrated LED indicators provide Visual status for operation and signal activity.

Which media is compatible with the controller’s pneumatic interfaces?

It is intended for use with Air as the control medium in pneumatic circuits.

Are there any environmental limits for installation?

The operating temperature range is -10°C to +50°C, defining suitable ambient conditions.

What body form factor assists in Compact installations?

The housing depth and upright profile allow installation where panel space is restricted, with a narrow width of 28mm for dense mounting.
