PicoScope 6000E Series, 1 GHz PC Based Oscilloscope 4-Channel

RS 제품 번호:: 222-2084
제조사 부품 번호:: PicoScope 6406E
제조업체:: Pico Technology

PicoScope 6000E Series, 1 GHz PC Based Oscilloscope 4-Channel

모든 Oscilloscopes 열람하기

Subtotal (1 unit)*

₩24,507,400.00

재고있음

1 개 단위 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩24,507,400.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 222-2084
제조사 부품 번호:: PicoScope 6406E
제조업체:: Pico Technology

사양

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Pico Technology
	Product Type	Oscilloscope
	Bandwidth	1GHz
	Number of Channels	4
	Model Number	PicoScope 6406E
	Oscilloscope Type	PC Based
	Interface Type	USB
	Series	PicoScope 6000E
	Height	61.50mm
	Length	245mm
	Standards/Approvals	EN 61010, EN 613261:2013, REACH, RoHS, WEEE
	Width	192mm
	Maximum Vertical Sensitivity	4V/div
	Minimum Vertical Sensitivity	2mV/div
	Minimum Time Base	1ns/div
	Rise Time	850ps
	Maximum Time Base	5000s/div
	Power Source	USB
	Vertical Resolution	8 bit

	모두 선택
	브랜드 Pico Technology
	Product Type Oscilloscope
	Bandwidth 1GHz
	Number of Channels 4
	Model Number PicoScope 6406E
	Oscilloscope Type PC Based
	Interface Type USB
	Series PicoScope 6000E
	Height 61.50mm
	Length 245mm
	Standards/Approvals EN 61010, EN 613261:2013, REACH, RoHS, WEEE
	Width 192mm
	Maximum Vertical Sensitivity 4V/div
	Minimum Vertical Sensitivity 2mV/div
	Minimum Time Base 1ns/div
	Rise Time 850ps
	Maximum Time Base 5000s/div
	Power Source USB
	Vertical Resolution 8 bit

COO (Country of Origin):: GB

PicoScope 6000E Series Oscilloscope, 1 GHz Bandwidth, 4 Channels - PicoScope 6406E

This oscilloscope is a PC‑connected instrument that captures and displays electrical signals for analysis. It is powered and interfaced via USB and operates as a compact, USB‑driven solution suitable for laboratory and workshop environments. The instrument supports Rapid signal acquisition across four inputs and complies with relevant European safety and environmental standards.

Features and Benefits:

• 1 ns/div minimum time base enables observation of fast time‑domain events
• 1GHz bandwidth delivers high‑frequency signal fidelity
• 850 ps rise time resolves fast edge transitions
• 8‑bit vertical resolution provides clear amplitude representation
• 2 mV/div minimum sensitivity detects low‑level signals

Applications

• Suitable for high‑speed digital signal analysis tasks
• Ideal for multi‑channel transient capture on test benches
• Used for USB‑powered field measurements and diagnostics
• Can be used for educational laboratory waveform demonstrations

How is the instrument powered during use?

It receives power through the USB connection, eliminating separate power supplies.

What safety and environmental standards does it meet?

The unit conforms to EN 61010, EN 61326‑1:2013, REACH, RoHS and WEEE requirements.

What vertical input range can I expect for amplitude measurements?

The instrument supports vertical sensitivities from 2 mV/div up to 4 V/div to cover low to moderate amplitudes.

What physical form factor should I plan for on a test bench?

The enclosure measures 61.50 mm high by 245 mm long by 192 mm wide for Compact placement.
