PicoScope 9400 Series, 16 GHz PC Based Oscilloscope 4-Channel

모든 Oscilloscopes 열람하기

Subtotal (1 unit)*

₩49,555,660.00

Add to Basket
수량 선택 또는 입력
일시적 품절
  • 2027년 2월 12일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 +₩49,555,660.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
232-2206
제조사 부품 번호:
PicoScope 9404-16
제조업체:
Pico Technology
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Pico Technology

Product Type

Oscilloscope

Bandwidth

16GHz

Number of Channels

4

Model Number

PicoScope 9404-16

Oscilloscope Type

PC Based

Interface Type

USB

Series

PicoScope 9400

Height

60mm

Length

232mm

Standards/Approvals

EN61010-1:2010, EN61326-1:2013

Width

245mm

Maximum Vertical Sensitivity

250mV/div

Minimum Time Base

20ps/div

Rise Time

50ps

Maximum Time Base

1000s/div

Power Source

AC Adapter

Vertical Resolution

12 bit

Minimum Vertical Sensitivity

10mV/div

COO (Country of Origin):
LT

PicoScope 9400 Series Oscilloscope, 16GHz Bandwidth, 4 Channels - PicoScope 9404-16


This oscilloscope is a PC-connected instrument designed for high-speed signal observation and analysis in laboratory and test environments. It connects via a universal USB/interface and runs from an AC adaptor, offering a Compact footprint suited to bench and portable use. Built to applicable safety and EMC standards, it supports detailed waveform capture across multiple inputs for engineers and technicians requiring precise temporal measurement.

Features and Benefits:


• 16GHz bandwidth provides wide-frequency signal capture and analysis
• 50ps rise time enables accurate edge-transition characterisation
• 12-bit vertical resolution improves amplitude fidelity for low-noise signals
• 10mV/div sensitivity allows detection of small signal variations
• 20ps/div minimum time base delivers high-resolution time-domain views

Applications


• Suitable for high-speed digital bus validation and debugging
• Used for component characterisation in RF and microwave testing
• Ideal for time-domain jitter and edge analysis tasks
• Can be used for multi-channel synchronised signal comparison
• Used with PC-based automation for automated test routines

What power options are available for operation?


It operates from an AC adaptor and requires mains connection for use.

How is the instrument connected to a host computer?


A universal USB/interface provides the communications link to a PC.

What standards does it conform to for safety and EMC?


It meets EN61010-1:2010 for safety and EN61326-1:2013 for EMC.

What channel count is provided for simultaneous measurements?


Four independent channels permit concurrent acquisition of multiple signals.
