- RS 제품 번호:
- 202-2046
- 제조사 부품 번호:
- 110.083.101
- 제조업체:
- ROLEC
21 <재고있음> 5-9영업일내 홍콩 발송
추가완료!
단가 개당
₩82,196.66
수량 | 한팩당 |
1 - 24 | ₩82,196.66 |
25 - 49 | ₩78,912.45 |
50 + | ₩76,316.476 |
- RS 제품 번호:
- 202-2046
- 제조사 부품 번호:
- 110.083.101
- 제조업체:
- ROLEC
제정법과 컴플라이언스
- COO (Country of Origin):
- DE
제품 세부 사항
RFI Shielded Boxes
This RS Pro Aluminium Enclosure is a highly versatile and economic enclosure that has in-built shielding. The pre-cast lid and base has tooth system, which ensures continuous contact.
The threaded screw bosses are provided insude for fitting types of boards to be fitted.
An IP66 seal, ensures this enclosure is dust proof and weather resistant..
Features and Benefits
Baked enamel heavy-duty boxes with overlapping tongue and groove to provide a high level of RFI screening
Neoprene sealing gasket provides protection to IP66
Internal mounts for PCBs, earth tags etc (supplied with copper plated screws)
Lid to box fixing screws and mounting holes are outside gasket area
Temperature range of -40 to +80°C
Body colour grey (RAL7032)
Neoprene sealing gasket provides protection to IP66
Internal mounts for PCBs, earth tags etc (supplied with copper plated screws)
Lid to box fixing screws and mounting holes are outside gasket area
Temperature range of -40 to +80°C
Body colour grey (RAL7032)
Typical Applications
Test and Measurement Instrumentation
Medical Tools
Transportation Equipment
Industrial Controls
Lighting Applications
What is Supplied?
This enclosure comes complete with captive screws
사양
속성 | 값 |
---|---|
Body Material | Die Cast Aluminium |
External Length | 179 mm |
External Height | 67 mm |
External Width | 84 mm |
External Dimensions | 179 x 84 x 67mm |
IP Rating | IP66, IP67 |
Colour | Grey |
Lid Colour | Grey |
Shielded | Yes |
Series | Conform |
