    USB, D Sub & Computing Connectors

    We have a large range of data, electrical and computing connectors for both office and domestic uses. You'll find memory and SIM card connectors, type A, B, C, mini and micro USB connectors as well as D-sub connectors, kits and backshells. We stock many manufacturers that include TE Connectivity, MH Connectors and Harting or try our own brand RS PRO.

    What is a computer connector?

    Computing systems have many accessories and devices that they need to work with for example to transfer data or power. A connector is used to join conductors electrically or mechanically together.

    There are lots of different kinds of connectors available that are designed for different applications. Here is an overview of some of the most popular connectors and what they are used for.

    D-subminiature connectors types

    D-sub connectors have a d-shaped shield that screens interference and 2 rows of pins with varying configurations. They can be cable or board mounted and are commonly used for display and serial-port communications. Our range includes replaceable parts such as backshells (housing), screw locks and contacts. Common types are:

    • Standard density D-sub connectors
    • High-density D-sub connectors
    • PCB D-sub connectors

    USB connectors types

    Used for both power and data transfer between computers and devices. There are different types of USB connector available:

    • Type A: Rectangular in shape – the standard USB port
    • Type B: Almost square in shape, mostly used for peripherals like printers.
    • Mini & Micro B: Used with small devices such as smartphones, cameras and wearable devices
    • Type C: The newest and smallest USB connector that is symmetrical in shape with 24 pins, in 2 rows of 12

    Memory and sim card connectors

    Receptacles for sim and memory storage cards to be used in devices such as laptops, phones and cameras.

    Selecting a connector

    Along with the application the connector is designed for, they have different attributes to consider when choosing which connector to use in a system:

    • Number of positions for installation
    • Style
    • Orientation
    • Termination - crimp, solder or other
    • Mating Type
    • Material
    • Mounting method

    10243 표시되는 제품 USB, D Sub & Computing Connectors

    482 / 513
    • RS 제품 번호 885-8964
    • 제조사 부품 번호 DAUH-15P
    개당
    ₩32,655.60
    • RS 제품 번호 201-7061
    • 제조사 부품 번호 SLP-06V
    500 백 1개
    ₩277,110.12
    • RS 제품 번호 560-512
    • 제조사 부품 번호 6355-0030-12
    개당
    ₩3,870.92
    • RS 제품 번호 207-5897
    • 제조사 부품 번호 FMP002P106 / 1731120091
    개당
    ₩3,496.80
    • RS 제품 번호 795-0735
    • 제조사 부품 번호 5749721-7
    개당
    ₩20,228.80
    • RS 제품 번호 923-5296
    • 제조사 부품 번호 09692827423
    개당가격(100개가 1박스안에)
    ₩3,758.12
    • RS 제품 번호 240-7940
    • 제조사 부품 번호 750-963
    개당
    ₩106,107.20
    • RS 제품 번호 865-8294
    • 제조사 부품 번호 09672504704
    개당
    ₩18,542.44
    • RS 제품 번호 179-2805
    • 제조사 부품 번호 L17D45ZK09+L717HDE15P
    개당
    ₩20,042.68
    • RS 제품 번호 174-8468
    • 제조사 부품 번호 172-E25-103R001
    개당가격(50개가 1트레이안에)
    ₩5,497.12
    • RS 제품 번호 285-7401
    • 제조사 부품 번호 DTS50PYC/2M63UN
    개당
    ₩53,843.20
    • RS 제품 번호 278-4279
    • 제조사 부품 번호 L17ED09S10
    개당
    ₩23,462.40
    • RS 제품 번호 194-6530
    • 제조사 부품 번호 USB3FTV7ANF312
    개당
    ₩218,174.00
    • RS 제품 번호 185-9876
    • 제조사 부품 번호 1565917-4
    개당
    ₩11,110.80
    • RS 제품 번호 259-2292
    • 제조사 부품 번호 004125
    개당
    ₩12,859.20
    • RS 제품 번호 322-0746
    • 제조사 부품 번호 S-1608A(09)
    개당
    ₩3,308.80
    • RS 제품 번호 160-0493
    • 제조사 부품 번호 DAM7W2SN
    개당
    ₩10,904.00
    • RS 제품 번호 471-703
    • 제조사 부품 번호 100504L
    75 미터가 들어있는 1트레이
    ₩297,688.60
    • RS 제품 번호 204-1640
    • 제조사 부품 번호 SDF-S25-103L011
    개당가격(36개가 1트레이안에)
    ₩15,643.48
    • RS 제품 번호 121-6793
    • 제조사 부품 번호 629004113921
    개당가격(43개가 1튜브안에)
    ₩2,378.20
