RS PRO 230 V ac 2 x 40 V ac Toroidal Transformer 2 Output 1000 VA, UL51, UL506, EN60065 Class II, EN615581 Class II
- RS 제품 번호:
- 123-4005
- 제조업체:
- RS PRO
Subtotal (1 unit)*
₩333,681.20
재고있음
- 1 개 단위 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩333,681.20 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 123-4005
- 제조업체:
- RS PRO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RS PRO | |
| Product Type | Toroidal Transformer | |
| Primary Voltage | 230 V ac | |
| Secondary Voltage | 2 x 40 V ac | |
| Number of Outputs | 2 | |
| Power | 1000VA | |
| Weight | 6.5kg | |
| Diameter | 162mm | |
| Minimum Operating Frequency | 50Hz | |
| Winding Type | Dual Secondary, Single Primary | |
| Maximum Operating Frequency | 60Hz | |
| Minimum Operating Temperature | 105°C | |
| Maximum Operating Temperature | 180°C | |
| Mount Type | Surface Mount | |
| Height | 70mm | |
| Termination Type | Leadout | |
| Standards/Approvals | UL51, UL506, EN60065 Class II, EN615581 Class II | |
| 모두 선택 | ||
|---|---|---|
브랜드 RS PRO | ||
Product Type Toroidal Transformer | ||
Primary Voltage 230 V ac | ||
Secondary Voltage 2 x 40 V ac | ||
Number of Outputs 2 | ||
Power 1000VA | ||
Weight 6.5kg | ||
Diameter 162mm | ||
Minimum Operating Frequency 50Hz | ||
Winding Type Dual Secondary, Single Primary | ||
Maximum Operating Frequency 60Hz | ||
Minimum Operating Temperature 105°C | ||
Maximum Operating Temperature 180°C | ||
Mount Type Surface Mount | ||
Height 70mm | ||
Termination Type Leadout | ||
Standards/Approvals UL51, UL506, EN60065 Class II, EN615581 Class II | ||
RS PRO 230 V AC, 2 x 40 V AC Toroidal Transformer, 1000 VA, 2 Output
This RS PRO toroidal transformer is ideal for stepping voltage up or down in control circuits. It has a primary voltage rating of 230 V AC and a secondary voltage rating of 2 x 40 V AC, so you have the option to charge two devices simultaneously.
The transformer's core delivers low loss and low noise for more reliable performance. It incorporates primary windings and twin secondary windings, which you can connect either in series or in parallel to build multiple circuit layouts. The centre hole fixing enables you to mount the transformer easily. Low energy dissipation makes this an efficient and environmentally friendly component.
It's Restriction of Hazardous Substances certified, which guarantees that it's free of harmful materials. This part is frequently used to power electrical appliances such as computers, home theatre installations and cordless power tools.
Features and benefits
• Double output
• Lead wire termination type
• Surface mounting
• Operating frequency of 50 to 60 Hz
• Diameter of 162 mm
• Height of 70 mm
• Weight of 6.5 kg
• Power rating of 1000 VA
