RS PRO 230 V ac 2 x 55 V ac Toroidal Transformer 2 Output, EN615581 Class II, UL506, EN60065 Class II, UL51
- RS 제품 번호:
- 123-3991
- 제조업체:
- RS PRO
Subtotal (1 unit)*
₩152,938.00
일시적 품절
- 3 개 단위 배송 준비 완료
- 추가로 2026년 7월 27일 부터 20 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩152,938.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 123-3991
- 제조업체:
- RS PRO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RS PRO | |
| Product Type | Toroidal Transformer | |
| Primary Voltage | 230 V ac | |
| Secondary Voltage | 2 x 55 V ac | |
| Number of Outputs | 2 | |
| Secondary Current | 2.73 A | |
| Weight | 2.3kg | |
| Diameter | 115 mm | |
| Minimum Operating Frequency | 50Hz | |
| Maximum Operating Frequency | 60Hz | |
| Winding Type | Single Primary, Dual Secondary | |
| Minimum Operating Temperature | 105°C | |
| Maximum Operating Temperature | 180°C | |
| Mount Type | Surface Mount | |
| Height | 70mm | |
| Termination Type | Wire | |
| Standards/Approvals | EN615581 Class II, UL506, EN60065 Class II, UL51 | |
| 모두 선택 | ||
|---|---|---|
브랜드 RS PRO | ||
Product Type Toroidal Transformer | ||
Primary Voltage 230 V ac | ||
Secondary Voltage 2 x 55 V ac | ||
Number of Outputs 2 | ||
Secondary Current 2.73 A | ||
Weight 2.3kg | ||
Diameter 115 mm | ||
Minimum Operating Frequency 50Hz | ||
Maximum Operating Frequency 60Hz | ||
Winding Type Single Primary, Dual Secondary | ||
Minimum Operating Temperature 105°C | ||
Maximum Operating Temperature 180°C | ||
Mount Type Surface Mount | ||
Height 70mm | ||
Termination Type Wire | ||
Standards/Approvals EN615581 Class II, UL506, EN60065 Class II, UL51 | ||
RS Pro Open Style Toroidal Transformers 300VA-1000VA
RS Pro High-quality open toroidal transformers with a single 230 Vac 50/60 Hz primary winding. Twin secondary windings can be connected in series or parallel or used independently. Designed for easy mounting with centre hole fixing.
Standards
UL506
UL5085-1
EN61558-1 Class II
EN60065 Class II
UL5085-1
EN61558-1 Class II
EN60065 Class II
