STMicroelectronics 5-Pin Sound Sensor, Omni-Directional, Surface, Analogue Output, RHLGA-5L 1.52 V 3.6 V
- RS 제품 번호:
- 208-5070
- 제조사 부품 번호:
- IMP23ABSUTR
- 제조업체:
- STMicroelectronics
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
- RS 제품 번호:
- 208-5070
- 제조사 부품 번호:
- IMP23ABSUTR
- 제조업체:
- STMicroelectronics
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | STMicroelectronics | |
| Technology | MEMS Microphone | |
| Product Type | Sound Sensor | |
| Frequency Range | 2.9 to 3.6 MHz | |
| Output Type | Analogue | |
| Directivity | Omni-Directional | |
| Sensitivity | 1kHz | |
| Signal to Noise Ratio | 64dB | |
| Minimum Supply Voltage | 1.52V | |
| Mount Type | Surface | |
| Maximum Supply Voltage | 3.6V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Package Type | RHLGA-5L | |
| Standards/Approvals | No | |
| Height | 1.08mm | |
| Pin Count | 5 | |
| Length | 3.5mm | |
| Port Location | Bottom | |
| Automotive Standard | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 STMicroelectronics | ||
Technology MEMS Microphone | ||
Product Type Sound Sensor | ||
Frequency Range 2.9 to 3.6 MHz | ||
Output Type Analogue | ||
Directivity Omni-Directional | ||
Sensitivity 1kHz | ||
Signal to Noise Ratio 64dB | ||
Minimum Supply Voltage 1.52V | ||
Mount Type Surface | ||
Maximum Supply Voltage 3.6V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Package Type RHLGA-5L | ||
Standards/Approvals No | ||
Height 1.08mm | ||
Pin Count 5 | ||
Length 3.5mm | ||
Port Location Bottom | ||
Automotive Standard No | ||
The STMicroelectronics IMP23ABSU is a compact, low-power microphone built with a capacitive sensing element and an IC interface. The sensing element, capable of detecting acoustic waves, is manufactured using specialized silicon micromachining process to produce audio sensors.
Omnidirectional sensitivity
High signal-to-noise ratio
High acoustic overload point: 130 dBSPL typ.
Package compliant with reflow soldering
Enhanced RF immunity
Ultra-flat frequency response
Ultrasound bandwidth (up to 80 kHz)
Low latency
