Werma KombiSIGN 40 Series Yellow Flashing Effect Beacon Tower, LED Bulb 24V dc, DC, IP66
- RS 제품 번호:
- 123-2901
- 제조사 부품 번호:
- 634.340.55
- 제조업체:
- Werma
Subtotal (1 unit)*
₩180,628.50
제조사가 재고 비축중
- 2026년 7월 14일 부터 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩180,628.50 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 123-2901
- 제조사 부품 번호:
- 634.340.55
- 제조업체:
- Werma
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Werma | |
| Product Type | Beacon Tower | |
| Series | KombiSIGN 40 | |
| Minimum Sound Level | 89dB | |
| Current Type | DC | |
| Light Effect | Flashing | |
| Mount Type | Base | |
| Lens Colour | Yellow | |
| Lamp Included | Yes | |
| Bulb Type | LED | |
| Maximum Supply Voltage | 24V dc | |
| Minimum Operating Temperature | -30°C | |
| Maximum Sound Level | 95dB | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | CE Certified | |
| Height | 59mm | |
| Base Diameter | 40mm | |
| Hazardous Area Certification | No | |
| IP Rating | IP66 | |
| Housing Colour | Clear | |
| 모두 선택 | ||
|---|---|---|
브랜드 Werma | ||
Product Type Beacon Tower | ||
Series KombiSIGN 40 | ||
Minimum Sound Level 89dB | ||
Current Type DC | ||
Light Effect Flashing | ||
Mount Type Base | ||
Lens Colour Yellow | ||
Lamp Included Yes | ||
Bulb Type LED | ||
Maximum Supply Voltage 24V dc | ||
Minimum Operating Temperature -30°C | ||
Maximum Sound Level 95dB | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals CE Certified | ||
Height 59mm | ||
Base Diameter 40mm | ||
Hazardous Area Certification No | ||
IP Rating IP66 | ||
Housing Colour Clear | ||
Stacking Signal Tower - KombiSIGN 40, 40mm
The WERMA KombiSIGN 40 modular stacking signal tower is an ideal solution to the increasing requirement for safety, machine productivity and reduced downtime. Each KombiSIGN module is equipped with a bayonet fixing with integral contact system. The modular design of these stacking towers enables quick and easy installation.
Features and Benefits
• Suitable for machine and manual Andon indication
• Modular system allows a completely free combination of optical and audible signal elements
• Mechanical and electrical connection of the elements in seconds using a bayonet connection system
• Completely safe element changes (contact-voltage proof) without the need for tools
• Protection rating IP66
• Up to 5 elements can be mounted on a terminal base
• Flexible combination of optical and audible elements
• Optical isolation due to O-ring seal stopping illumination of adjacent element
• Operating temperature range is -30 to +60 °C
• Polycarbonate 40 mm diameter
