제조사부품번호

KOA, CN 330Ω ±5% Isolated Resistor Array, 4 Resistors, 0603 (1608M), Concave

대량 구매 할인 기용 가능

Subtotal (1 pack of 100 units)*

₩4,324.00

마지막 RS 재고

* 참고 가격: 실제 구매가격과 다를 수 있습니다

사양

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	KOA
	Resistance	330Ω
	Number of Resistors	4
	Resistor Type	Array
	Package/Case	0603 (1608M)
	Termination Style	Concave
	Tolerance	±5%
	Automotive Standard	AEC-Q200
	Case Style	Moulded
	Power Rating per Resistor	0.063W
	Circuit Designator	ISOL
	Length	3.2mm
	Depth	1.6mm
	Height	0.6mm
	Dimensions	3.2 x 1.6 x 0.6mm
	Number of Terminals	8
	Series	CN
	Temperature Coefficient	±200ppm/°C
	Minimum Operating Temperature	-55°C
	Maximum Operating Temperature	+155°C

	모두 선택
	브랜드 KOA
	Resistance 330Ω
	Number of Resistors 4
	Resistor Type Array
	Package/Case 0603 (1608M)
	Termination Style Concave
	Tolerance ±5%
	Automotive Standard AEC-Q200
	Case Style Moulded
	Power Rating per Resistor 0.063W
	Circuit Designator ISOL
	Length 3.2mm
	Depth 1.6mm
	Height 0.6mm
	Dimensions 3.2 x 1.6 x 0.6mm
	Number of Terminals 8
	Series CN
	Temperature Coefficient ±200ppm/°C
	Minimum Operating Temperature -55°C
	Maximum Operating Temperature +155°C

Concave termination with square corners resistor array

Less board space than individual chips
Isolated resistor elements
