KOA, CN 100Ω ±5% Isolated Resistor Array, 8 Resistors, 1206 (3216M), Concave
- RS 제품 번호:
- 172-9238
- 제조사 부품 번호:
- CN2B8TTE101J
- 제조업체:
- KOA
대량 구매 할인 기용 가능
Subtotal (1 pack of 100 units)**
₩175,780.00
2600 재고있음 5-9영업일내 홍콩 발송*
* 배송 날짜는 선택한 수량과 배송 주소에 따라 달라질 수 있습니다.
재고 확인하기
수량 | 한팩당 | 한팩당** |
---|---|---|
100 - 100 | ₩1,757.80 | ₩175,855.20 |
200 - 400 | ₩1,671.32 | ₩167,056.80 |
500 + | ₩1,586.72 | ₩158,709.60 |
** 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 172-9238
- 제조사 부품 번호:
- CN2B8TTE101J
- 제조업체:
- KOA
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
---|---|---|
브랜드 | KOA | |
Resistance | 100Ω | |
Number of Resistors | 8 | |
Resistor Type | Array | |
Package/Case | 1206 (3216M) | |
Termination Style | Concave | |
Tolerance | ±5% | |
Automotive Standard | AEC-Q200 | |
Case Style | Moulded | |
Power Rating per Resistor | 0.125W | |
Circuit Designator | ISOL | |
Length | 10.16mm | |
Depth | 3.2mm | |
Height | 0.6mm | |
Dimensions | 10.16 x 3.2 x 0.6mm | |
Series | CN | |
Number of Terminals | 16 | |
Maximum Operating Temperature | +155°C | |
Temperature Coefficient | ±200ppm/°C | |
Minimum Operating Temperature | -55°C | |
