Eaton Electronic Circuit Breaker, 20 A Current Rating, 2-Pole, 30 mA Trip Sensitivity, Type C, Eaton Moeller Range,
- RS 제품 번호:
- 246-612
- 제조사 부품 번호:
- 187275 AFDD-20/2/C/003-F
- 제조업체:
- Eaton
Subtotal (1 unit)*
₩388,174.88
일시적 품절
- 2026년 4월 23일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩388,174.88 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 246-612
- 제조사 부품 번호:
- 187275 AFDD-20/2/C/003-F
- 제조업체:
- Eaton
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Eaton | |
| Current Rating | 20 A | |
| Product Type | Electronic Circuit Breaker | |
| Number of Poles | 2 | |
| Series | Eaton Moeller series xPole - AFDD+ | |
| Range | Eaton Moeller | |
| Trip Sensitivity | 30mA | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 230 V ac | |
| Depth | 52.5mm | |
| Height | 73mm | |
| Width | 80 mm | |
| Standards/Approvals | IEC/EN 61009 | |
| Application | Switch Gear | |
| Breaking Capacity | 10kA | |
| 모두 선택 | ||
|---|---|---|
브랜드 Eaton | ||
Current Rating 20 A | ||
Product Type Electronic Circuit Breaker | ||
Number of Poles 2 | ||
Series Eaton Moeller series xPole - AFDD+ | ||
Range Eaton Moeller | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 230 V ac | ||
Depth 52.5mm | ||
Height 73mm | ||
Width 80 mm | ||
Standards/Approvals IEC/EN 61009 | ||
Application Switch Gear | ||
Breaking Capacity 10kA | ||
제외
- COO (Country of Origin):
- CZ
The Eaton afdd+ arc fault detection device is a cutting-edge solution designed to enhance safety in both residential and commercial settings. With its two-pole configuration and C20A rating, this device significantly mitigates the risk of electrical fires caused by arc faults. Built for reliability, it operates within a voltage rating of 230V and features advanced fault current sensitivity, enabling rapid response to potentially hazardous conditions. The compact design, coupled with a robust IP40 degree of protection, makes it suitable for various installation environments. Compliant with stringent standards, this device is a trustworthy choice for ensuring peace of mind in electrical installations.
Compact dimensions allow for versatile installations in limited spaces
Two-pole configuration provides effective arc fault protection
Robust design ensures long-lasting performance in harsh conditions
Quick response time enhances safety by preventing electrical fires
Compliant with RoHS, demonstrating commitment to environmental responsibility
High operational lifespan, reducing the need for frequent replacements
Backed by Eaton’s reputation for quality and reliability in electrical solutions
Enhanced sensitivity caters to various electrical applications
