ABB Compact Series Push Button Switch, Momentary, Panel, 22 mm Cutout, DPST, IP20, IP66, IP67, IP69K, 125 V

RS 제품 번호:: 479-3649
제조사 부품 번호:: 1SFA619100R1021 CP1-10R-20
제조업체:: ABB

ABB Compact Series Push Button Switch, Momentary, Panel, 22 mm Cutout, DPST, IP20, IP66, IP67, IP69K, 125 V

모든 Push Button Switches 열람하기

대량 구매 할인 기용 가능

View bulk pricing options

Subtotal (1 unit)*

₩23,946.00

재고있음

추가로 2026년 6월 29일 부터 76 개 단위 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 - 5	₩23,946.00
6 - 11	₩23,614.50
12 +	₩23,146.50

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 479-3649
제조사 부품 번호:: 1SFA619100R1021 CP1-10R-20
제조업체:: ABB

사양

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	ABB
	Actuator Colour	Red
	Product Type	Push Button Switch
	Switch Operation	Momentary
	Illuminated	No
	Series	Compact
	Panel Cutout Size	22 mm
	Mount Type	Panel
	Contact Configuration	DPST
	Terminal Type	Screw
	IP Rating	IP20, IP66, IP67, IP69K
	Contact DC Voltage	125V
	Actuator Style	Round
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	70°C
	Height	30mm
	Length	55mm
	Standards/Approvals	IEC 947-5-5EN 60204
	Width	30mm

	모두 선택
	브랜드 ABB
	Actuator Colour Red
	Product Type Push Button Switch
	Switch Operation Momentary
	Illuminated No
	Series Compact
	Panel Cutout Size 22 mm
	Mount Type Panel
	Contact Configuration DPST
	Terminal Type Screw
	IP Rating IP20, IP66, IP67, IP69K
	Contact DC Voltage 125V
	Actuator Style Round
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 70°C
	Height 30mm
	Length 55mm
	Standards/Approvals IEC 947-5-5EN 60204
	Width 30mm

제외

COO (Country of Origin):: CN

ABB Compact Series Push Button Switch, Red Actuator, 22mm Panel Cutout Size - 1SFA619100R1021 CP1-10R-20

This push button switch provides a compact, panel-mounted control input for industrial systems, offering momentary actuation for on/off control in automation and electrical installations. It is designed for use where a robust, visible red round actuator is required and where screw-type terminations and a dual-pole switching arrangement are appropriate.

Features and Benefits:

• DPST contact arrangement enabling simultaneous dual-circuit switching
• Momentary operation for temporary control and safety interlocks
• Rated for 125V DC to support low-voltage control circuits
• Screw Terminal connections for secure field wiring
• Wide ingress protection options to suit harsh environments
• Operates between -25°C and 70°C for varied site conditions

Applications

• Suitable for machine control panels requiring a red push input
• Ideal for safety interlock circuits in manufacturing lines
• Used with control cabinets that accept 22mm panel cut-outs
• Can be used for temporary start/stop functions on test rigs
• Suitable for electrical panels needing DPST switching

What mounting provision is required for installation?

It requires a 22mm panel cut-out and is designed for panel mounting with a secure fit.

How is the switch terminated to the control wiring?

Connections are MADE via screw terminals that provide reliable mechanical and electrical contact.

What actuator and user Interface characteristics does it offer?

The actuator is round and red, intended for clear Visual identification and tactile momentary operation.

Which protection levels are available for use in demanding environments?

The product is offered with IP20, IP66, IP67 and IP69K ingress protection options to match exposure requirements.
