EAO 82 Series Illuminated Push Button Switch, Latching, Panel, 31 x 31 mm Cutout, SPDT, Green LED, IP67, IP65, 240 V dc
- RS 제품 번호:
- 239-4948
- Distrelec 제품 번호:
- 302-46-108
- 제조사 부품 번호:
- 82-6151.2A34.B001
- 제조업체:
- EAO
대량 구매 할인 기용 가능
Subtotal (1 unit)*
₩62,622.80
재고있음
- 5 개 단위 배송 준비 완료
- 추가로 2026년 3월 10일 부터 4 개 단위 배송
- 추가로 2026년 5월 26일 부터 17 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 - 9 | ₩62,622.80 |
| 10 - 49 | ₩59,878.00 |
| 50 + | ₩53,899.60 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 239-4948
- Distrelec 제품 번호:
- 302-46-108
- 제조사 부품 번호:
- 82-6151.2A34.B001
- 제조업체:
- EAO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | EAO | |
| Switch Operation | Latching | |
| Actuator Colour | Silver | |
| Product Type | Push Button Switch | |
| Illuminated | Yes | |
| Panel Cutout Size | 31 x 31 mm | |
| Series | 82 | |
| Mount Type | Panel | |
| Contact Configuration | SPDT | |
| LED Colour | Green | |
| IP Rating | IP67, IP65 | |
| Contact AC Voltage | 240V ac | |
| Minimum Operating Temperature | -30°C | |
| Contact DC Voltage | 240V dc | |
| Switch Configuration | Latching | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | CB, UL, CCC, cUL | |
| Switch Contact Current | 3 A | |
| Legend | On-Off | |
| 모두 선택 | ||
|---|---|---|
브랜드 EAO | ||
Switch Operation Latching | ||
Actuator Colour Silver | ||
Product Type Push Button Switch | ||
Illuminated Yes | ||
Panel Cutout Size 31 x 31 mm | ||
Series 82 | ||
Mount Type Panel | ||
Contact Configuration SPDT | ||
LED Colour Green | ||
IP Rating IP67, IP65 | ||
Contact AC Voltage 240V ac | ||
Minimum Operating Temperature -30°C | ||
Contact DC Voltage 240V dc | ||
Switch Configuration Latching | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals CB, UL, CCC, cUL | ||
Switch Contact Current 3 A | ||
Legend On-Off | ||
- COO (Country of Origin):
- CH
The EAO illuminated pushbutton with 22 mm diameter made with stainless steel 304. This is a 82 series silver colour flush mounted illuminated pushbutton. Illumination colour of this pushbutton is green having a "On/Off" symbol.
Vandal-resistant impact resistant to IK10
Front protection up to IP67
Gold contacts available for low voltages and currents
Optional illumination and laser markings
Excellent tactile feedback
Long service life more than 1 million cycles of operation
Stainless steel anodised aluminium or brass coloured switches
Typical application areas
Exposed public areas for e.g. ticketing and vending machines
Industrial machinery and factory equipment
Lifting and moving like elevators and people movers
Building management access control and security systems
Audio and video equipment
Medical equipment
Food industry
