RAFI 1.01 Series Illuminated Push Button Switch, Momentary, Through Hole, 18.2mm Cutout, 1 NC + 1 NO, 250V, IP40, IP65
- RS 제품 번호:
- 524-625
- 제조사 부품 번호:
- 1.01.102.011/0205
- 제조업체:
- RAFI
Subtotal (1 Bag of 5 units)*
₩99,734.00
일시적 품절
- 2026년 4월 15일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Bag(s) | Per Bag | 한팩당* |
|---|---|---|
| 1 + | ₩99,734.00 | ₩19,946.80 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 524-625
- 제조사 부품 번호:
- 1.01.102.011/0205
- 제조업체:
- RAFI
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RAFI | |
| Switch Operation | Momentary | |
| Illuminated | No | |
| Series | 1.01 | |
| Panel Cut Out Diameter | 18.2mm | |
| Mounting Type | Through Hole | |
| Push Button Colour | White | |
| Contact Configuration | 1 NC + 1 NO | |
| Voltage Rating | 250V | |
| IP Rating | IP40, IP65 | |
| 모두 선택 | ||
|---|---|---|
브랜드 RAFI | ||
Switch Operation Momentary | ||
Illuminated No | ||
Series 1.01 | ||
Panel Cut Out Diameter 18.2mm | ||
Mounting Type Through Hole | ||
Push Button Colour White | ||
Contact Configuration 1 NC + 1 NO | ||
Voltage Rating 250V | ||
IP Rating IP40, IP65 | ||
- COO (Country of Origin):
- HU
The RAFI Pushbutton features a momentary contact function. Sporting a bezel and a non-illuminated design, it is ideal for applications in mechanical and system engineering, model construction, and home technology. Its screw terminal ensures a secure and user-friendly installation.
White bezel colour
Mounting hole 18.2 mm
IP65 and IP40 protection
Contact function 1 NC plus 1 NO
RoHS and REACH compliant
Mounting hole 18.2 mm
IP65 and IP40 protection
Contact function 1 NC plus 1 NO
RoHS and REACH compliant
