Eaton M30C-FDL-X Series Momentary Spring Return Push Button Actuator, 30.5 mm Cutout, IP66, IP67, IP69

RS 제품 번호:: 273-6454
제조사 부품 번호:: 182941 M30C-FDL-X
제조업체:: Eaton

Eaton M30C-FDL-X Series Momentary Spring Return Push Button Actuator, 30.5 mm Cutout, IP66, IP67, IP69

Subtotal (1 unit)*

₩40,140.00

제조사가 재고 비축중

2026년 11월 16일 부터 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩40,140.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 273-6454
제조사 부품 번호:: 182941 M30C-FDL-X
제조업체:: Eaton

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Eaton
	Product Type	Push Button Actuator
	Series	M30C-FDL-X
	Cutout Diameter	30.5mm
	Push Button Shape	Round
	Push Button Actuation	Momentary Spring Return
	Push Button Style	Flat
	Push Button Material	Metal
	IP Rating	IP66, IP67, IP69
	Push Button Marking	Blank
	Push Button Diameter	30.5mm
	Standards/Approvals	IEC/EN 60947, VDE 0660
	Hazardous Area Certification	No

	모두 선택
	브랜드 Eaton
	Product Type Push Button Actuator
	Series M30C-FDL-X
	Cutout Diameter 30.5mm
	Push Button Shape Round
	Push Button Actuation Momentary Spring Return
	Push Button Style Flat
	Push Button Material Metal
	IP Rating IP66, IP67, IP69
	Push Button Marking Blank
	Push Button Diameter 30.5mm
	Standards/Approvals IEC/EN 60947, VDE 0660
	Hazardous Area Certification No

COO (Country of Origin):: DE

Eaton Push Button Actuator, 30.5mm Cutout Diameter, IP66, IP67, IP69 - 182941 M30C-FDL-X

This push-button actuator is an illuminated M30 front element designed for momentary control in industrial panels. It provides a flat, round metal front suitable for use where high ingress protection and robust front-ring mounting are required, offering tactile spring-return operation for short-duration commands in machinery or control stations.

Features and Benefits:

• IP69K-rated front to resist high-pressure washdown
• Spring-return actuation with 5N actuation force for consistent operation
• Mechanical life of 5,000,000 operations for extended duty
• Operates between -25°C and 70°C for a wide temperature range
• Compatible with SWD-RMQ connections for Smartwire-DT integration

Applications

• Suitable for food-processing lines requiring frequent washdown
• Ideal for outdoor control stations exposed to the weather
• Used with automated machinery needing momentary command inputs

What mounting cut-out is required for installation?

A 30.5 mm opening in the panel is needed for correct bezel seating.

What materials are used on the visible front to withstand impact?

The front bezel is metal with a titanium-coloured ring providing mechanical robustness.

How many command positions does it offer for operator input?

It provides a single command position with a spring-return momentary function.

What standards does it meet for electrical device compatibility?

It conforms to the IEC/EN 60947 family of standards and carries VDE 0660 approval.

What operational frequency can I expect during continuous use?

The actuator supports up to 3,600 operations per hour for repetitive switching.
