onsemi, Power Factor Correction IC 440 kHz 9-Pin, SOIC 30V

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

모든 Power Factor Correction 열람하기
대량 구매 할인 기용 가능
View bulk pricing options

Subtotal 20 units (supplied on a continuous strip)*

₩38,720.00

Add to Basket
수량 선택 또는 입력
마지막 RS 재고
  • 최종적인 1,470 개 unit(s)이 배송 준비 됨

수량
한팩당
20 - 90₩1,936.00
100 - 240₩1,878.00
250 - 490₩1,822.00
500 +₩1,768.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

포장 옵션
RS 제품 번호:
221-6582P
제조사 부품 번호:
FAN6921BMRMY
제조업체:
onsemi
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

onsemi

Product Type

Power Factor Correction IC

Start-up Supply Current

30μA

Maximum Source Current

45μA

Sub Type

Power Factor Controller

Switching Frequency

440kHz

Maximum Sink Current

40μA

Supply Current

10mA

Zero Power Detection

Yes

Package Type

SOIC

Pin Count

9

Minimum Supply Voltage

15V

Maximum Supply Voltage

30V

Minimum Operating Temperature

-40°C

Series

FAN6921B

Height

1.75mm

Length

10mm

Standards/Approvals

No

Maximum Operating Temperature

105°C

Automotive Standard

No

The ON Semiconductor highly integrated FAN6921BMR combines power factor correction (PFC) controller and quasi−resonant PWM controller. The integration provide cost effect design and allow for fewer external components. It uses a controlled on−time technique to provide a regulated DC output voltage and to perform natural power factor correction.

Zero−Current Detection for PFC Stage

Quasi−resonant operation for PWM stage

Internal minimum tOFF 8 ms for QR PWM stage

Internal 10 ms soft−start for PWM

Brownout Protection
