Phoenix Contact DFK-PC 5/6-GF-7.62 Series Pluggable Terminal Block, 6-Contact, 7.62 mm Pitch, 1 Row, 1727731

RS 제품 번호:: 854-9843
제조사 부품 번호:: 1727731
제조업체:: Phoenix Contact

Phoenix Contact DFK-PC 5/6-GF-7.62 Series Pluggable Terminal Block, 6-Contact, 7.62 mm Pitch, 1 Row, 1727731

현재 비가용

RS는 이 제품을 더 이상 판매하지 않습니다.

RS 제품 번호:: 854-9843
제조사 부품 번호:: 1727731
제조업체:: Phoenix Contact

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Phoenix Contact
	Number of Contacts	6
	Product Type	Pluggable Terminal Block
	Pitch	7.62mm
	Number of Rows	1
	Current	41A
	Housing Material	Polyamide
	Orientation	Right Angle
	Colour	Green
	Wire Connection Method	Solder
	Voltage	800 V
	Depth	21.1mm
	Width	80.34 mm
	Length	41.65mm
	Series	DFK-PC 5/6-GF-7.62
	Standards/Approvals	EU REACH SVHC, CSA, EU RoHS, cULus, CHINA RoHS

	모두 선택
	브랜드 Phoenix Contact
	Number of Contacts 6
	Product Type Pluggable Terminal Block
	Pitch 7.62mm
	Number of Rows 1
	Current 41A
	Housing Material Polyamide
	Orientation Right Angle
	Colour Green
	Wire Connection Method Solder
	Voltage 800 V
	Depth 21.1mm
	Width 80.34 mm
	Length 41.65mm
	Series DFK-PC 5/6-GF-7.62
	Standards/Approvals EU REACH SVHC, CSA, EU RoHS, cULus, CHINA RoHS

Datasheet 1727731

COO (Country of Origin):: PL

Feed-through header, nominal cross section: 6 mm², color: green, nominal current: 41 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 6, Number of rows: 1, Number of positions per row: 6, number of connections: 6, product range: DFK-PC 5/..-GF, pitch: 7.62 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 4.9 mm, Stecksystem: POWER COMBICON 5, Locking: Screw locking, type of packaging: packed in cardboard

Phoenix Contact DFK-PC 5/6-GF-7.62 Series Pluggable Terminal Block, 6-Contact, 7.62 mm Pitch, 1 Row, 1727731
