WAGO 2636 Series PCB Connector, 8-Contact, 10 mm Pitch, Feed Through, 1 Row
- RS 제품 번호:
- 221-059
- 제조사 부품 번호:
- 2636-1108/020-000
- 제조업체:
- WAGO
Subtotal (1 Box of 20 units)*
₩3,966,500.00
일시적 품절
- 2026년 10월 26일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩3,966,500.00 | ₩198,324.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 221-059
- 제조사 부품 번호:
- 2636-1108/020-000
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Number of Contacts | 8 | |
| Product Type | PCB Connector | |
| Pitch | 10mm | |
| Current | 76A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.75mm² | |
| Mount Type | Feed Through | |
| Housing Material | Polyamide 66 | |
| Maximum Wire Size mm² | 25mm² | |
| Minimum Wire Size AWG | 18AWG | |
| Maximum Wire Size AWG | 4AWG | |
| Orientation | 0° | |
| Wire Connection Method | Push-in | |
| Colour | Grey | |
| Voltage | 1000V | |
| Width | 81.6mm | |
| Standards/Approvals | No | |
| Depth | 29.1mm | |
| Series | 2636 | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Number of Contacts 8 | ||
Product Type PCB Connector | ||
Pitch 10mm | ||
Current 76A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.75mm² | ||
Mount Type Feed Through | ||
Housing Material Polyamide 66 | ||
Maximum Wire Size mm² 25mm² | ||
Minimum Wire Size AWG 18AWG | ||
Maximum Wire Size AWG 4AWG | ||
Orientation 0° | ||
Wire Connection Method Push-in | ||
Colour Grey | ||
Voltage 1000V | ||
Width 81.6mm | ||
Standards/Approvals No | ||
Depth 29.1mm | ||
Series 2636 | ||
The Wago PCB terminal block with Push-in CAGE CLAMP connectivity offers a robust solution for your electrical applications. Designed with versatility in mind, this terminal block effortlessly accommodates a variety of conductor types, ensuring secure connections with minimal installation effort. Its impressive specifications cater to both solid and fine-stranded conductors, making it ideal for efficient circuit design.
Wide limit temperature range ensures reliable performance in extreme conditions
Approvals from various standards assure compliance and safety
Lightweight construction aids in streamlined installations
