WAGO 713 Series Straight Through Hole Header, 10 Contact(s), 3.5 mm Pitch, 2 Row, Shrouded
- RS 제품 번호:
- 224-176
- 제조사 부품 번호:
- 713-1405/037-000
- 제조업체:
- WAGO
Subtotal (1 Box of 50 units)*
₩551,627.72
일시적 품절
- 2026년 2월 13일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩551,627.72 | ₩11,031.84 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 224-176
- 제조사 부품 번호:
- 713-1405/037-000
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Product Type | Header | |
| Series | 713 | |
| Pitch | 3.5mm | |
| Current | 10A | |
| Number of Contacts | 10 | |
| Housing Material | Polyphthalamide | |
| Number of Rows | 2 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Connector System | MCS | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Minimum Operating Temperature | 60°C | |
| Termination Type | Solder | |
| Row Pitch | 3.5mm | |
| Contact Gender | Male | |
| Tail Pin Length | 3.8mm | |
| Maximum Operating Temperature | 100°C | |
| Standards/Approvals | RoHS | |
| Voltage | 80 V | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Product Type Header | ||
Series 713 | ||
Pitch 3.5mm | ||
Current 10A | ||
Number of Contacts 10 | ||
Housing Material Polyphthalamide | ||
Number of Rows 2 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Connector System MCS | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Minimum Operating Temperature 60°C | ||
Termination Type Solder | ||
Row Pitch 3.5mm | ||
Contact Gender Male | ||
Tail Pin Length 3.8mm | ||
Maximum Operating Temperature 100°C | ||
Standards/Approvals RoHS | ||
Voltage 80 V | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header offers a robust solution for seamless connections in various electronic applications. Designed with two rows of solder pins, it ensures a compact and reliable interface. Its innovative 100% mismating protection and integrated locking mechanisms enhance usability while preventing accidental disconnections. The header is compatible with lead free reflow soldering, thanks to its THT compatible insulation material.
Integrated anti rotation protection for added stability
Variable coding options available for custom applications
PCB contact design supports straightforward integration into circuits
Lightweight construction facilitates easy handling and assembly
Robust electrical ratings ensure safe and efficient operation
Environmentally compliant materials promote sustainability
