WAGO 713 Series Straight Through Hole Header, 8 Contact(s), 3.5 mm Pitch, 2 Row, Shrouded
- RS 제품 번호:
- 223-472
- 제조사 부품 번호:
- 713-1404/037-000
- 제조업체:
- WAGO
Subtotal (1 Box of 50 units)*
₩441,301.80
일시적 품절
- 2026년 2월 13일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩441,301.80 | ₩8,826.60 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 223-472
- 제조사 부품 번호:
- 713-1404/037-000
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Series | 713 | |
| Product Type | Header | |
| Current | 10A | |
| Pitch | 3.5mm | |
| Housing Material | Polyphthalamide | |
| Number of Contacts | 8 | |
| Number of Rows | 2 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | MCS | |
| Mount Type | Through Hole | |
| Contact Material | Electrolytic Copper | |
| Contact Plating | Tin | |
| Termination Type | Solder | |
| Minimum Operating Temperature | 60°C | |
| Row Pitch | 3.5mm | |
| Tail Pin Length | 3.8mm | |
| Maximum Operating Temperature | 100°C | |
| Contact Gender | Male | |
| Standards/Approvals | RoHS | |
| Voltage | 25 V | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Series 713 | ||
Product Type Header | ||
Current 10A | ||
Pitch 3.5mm | ||
Housing Material Polyphthalamide | ||
Number of Contacts 8 | ||
Number of Rows 2 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System MCS | ||
Mount Type Through Hole | ||
Contact Material Electrolytic Copper | ||
Contact Plating Tin | ||
Termination Type Solder | ||
Minimum Operating Temperature 60°C | ||
Row Pitch 3.5mm | ||
Tail Pin Length 3.8mm | ||
Maximum Operating Temperature 100°C | ||
Contact Gender Male | ||
Standards/Approvals RoHS | ||
Voltage 25 V | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header is designed for versatility in connection applications, offering exceptional reliability and protection against mismating. This product accommodates configurations for both horizontal and vertical mounting, making it suitable for diverse PCB layouts. Crafted from high quality materials, it ensures optimal performance in demanding environments while supporting lead free reflow soldering processes.
Supports variable coding options to prevent mismating
Complies with strict environmental standards for improved sustainability
Offers a wide operating temperature range for adaptability in varied environments
Designed with an efficient pin spacing to facilitate compact PCB designs
Exhibits excellent flammability resistance for improved safety
Lightweight design aids in ease of handling during installation
