PicoScope 3000 Series, 200 MHz PC Based Oscilloscope 2-Channel

현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.

대체품

이 제품은 현재 공급 불가입니다. 아래 제품들은 당사에서 추천드리는 대체품입니다.

RS 제품 번호:
846-3418
Distrelec 제품 번호:
300-18-067
제조사 부품 번호:
PIcoScope 3206D
제조업체:
Pico Technology
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Pico Technology

Product Type

Oscilloscope

Bandwidth

200MHz

Number of Channels

2

Model Number

PicoScope 3206D

Oscilloscope Type

PC Based

Interface Type

CAN, IIC, LIN, RS232, SPI, UART, USB

Series

PicoScope 3000

Length

190mm

Width

170mm

Standards/Approvals

RoHS, WEEE

Height

40mm

Minimum Time Base

500ps/div

Minimum Vertical Sensitivity

4mV/div

Power Source

USB

Maximum Vertical Sensitivity

4V/div

Rise Time

1.75ns

Maximum Time Base

5000s/div

Vertical Resolution

8 bit

COO (Country of Origin):
GB

PicoScope 3000 Series Oscilloscope, 200MHz Bandwidth, 2 Channels - PIcoScope 3206D


This oscilloscope is a Compact PC‑connected instrument intended for waveform capture and analysis via a USB host. It offers a balance of speed and resolution for general laboratory and field diagnostics, supporting serial bus monitoring alongside standard analogue signal observation. The device is powered through the USB link and conforms to recognised environmental disposal standards.

Features and Benefits:


• 200MHz bandwidth delivers detailed high-frequency waveform capture
• 500ps/div minimum time base enables fine time‑domain resolution
• 8‑bit vertical resolution supports Rapid digitisation of signals
• 1.75ns rise time ensures accurate edge and transient measurement
• 4mV to 4V sensitivity range accommodates small and large signals

Applications


• Suitable for debugging CAN and LIN serial networks
• Ideal for analysing I²C and SPI communication timing
• Used for UART and RS232 signal verification in development
• Can be used for portable USB‑powered field diagnostics
• Used with PC software for detailed waveform recording

What interfaces are available for connecting peripheral devices?


It provides CAN, I²C, LIN, RS232, SPI, UART and USB interfaces for mixed‑signal measurement.

How is the instrument powered during operation?


The unit receives power via the USB connection to the host computer for portable use.

What environmental or disposal standards does the product meet?


It complies with RoHS and WEEE directives for restricted substances and waste handling.

What is the maximum selectable time base for long‑duration captures?


The maximum time base setting is 5000s/div for extended‑time observations.

Supplied with

Switchable x1/x10 probes (1 per analog channel) in carrying case, Quick Start guide, software and reference CD, USB cables, power adaptor (with 4 analog channel models only)
