PicoScope 9400 Series, 16 GHz PC Based Oscilloscope 4-Channel

RS 제품 번호:: 232-2207
제조사 부품 번호:: PicoScope 9404-16 CDR
제조업체:: Pico Technology

PicoScope 9400 Series, 16 GHz PC Based Oscilloscope 4-Channel

모든 Oscilloscopes 열람하기

Subtotal (1 unit)*

₩51,863,360.00

제조사가 재고 비축중

2027년 2월 12일 부터 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩51,863,360.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 232-2207
제조사 부품 번호:: PicoScope 9404-16 CDR
제조업체:: Pico Technology

사양

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Pico Technology
	Product Type	Oscilloscope
	Bandwidth	16GHz
	Number of Channels	4
	Model Number	PicoScope 9404-16 CDR
	Oscilloscope Type	PC Based
	Interface Type	USB
	Series	PicoScope 9400
	Width	245mm
	Standards/Approvals	DIN EN 50178, IEC 60664, IEC 62103
	Height	60mm
	Length	232mm
	Minimum Time Base	20ps/div
	Maximum Vertical Sensitivity	250mV/div
	Rise Time	50ps
	Minimum Vertical Sensitivity	10mV/div
	Maximum Time Base	1000s/div
	Power Source	AC Adapter
	Vertical Resolution	12 bit

	모두 선택
	브랜드 Pico Technology
	Product Type Oscilloscope
	Bandwidth 16GHz
	Number of Channels 4
	Model Number PicoScope 9404-16 CDR
	Oscilloscope Type PC Based
	Interface Type USB
	Series PicoScope 9400
	Width 245mm
	Standards/Approvals DIN EN 50178, IEC 60664, IEC 62103
	Height 60mm
	Length 232mm
	Minimum Time Base 20ps/div
	Maximum Vertical Sensitivity 250mV/div
	Rise Time 50ps
	Minimum Vertical Sensitivity 10mV/div
	Maximum Time Base 1000s/div
	Power Source AC Adapter
	Vertical Resolution 12 bit

COO (Country of Origin):: LT

PicoScope 9400 Series Oscilloscope, 16GHz Bandwidth, 12-bit Vertical Resolution - PicoScope 9404-16 CDR

This oscilloscope is a PC‑based instrument designed for high‑speed signal capture and analysis. It connects via a USB Interface and is powered through an AC adaptor, enabling use with laptops or desktop PCs for laboratory and field measurements. The unit adheres to relevant safety and insulation standards for use in electrified equipment environments.

Features and Benefits:

• 16GHz bandwidth enables observation of very high‑frequency signals
• 50ps rise time captures fast edge transitions accurately
• 12‑bit vertical resolution increases waveform detail and dynamic range
• Four independent channels support multi‑signal correlation
• 10mV/div vertical sensitivity permits small‑signal measurement

Applications

• Suitable for high‑speed digital signal integrity testing
• Ideal for characterising RF and microwave components
• Used with time‑domain measurement workflows in laboratories
• Can be used for multi‑channel transient capture and analysis
• Appropriate for development of fast‑edge analogue circuits

What connection method is used to Interface with a PC?

A USB Interface provides the digital link for data transfer and control.

How is the unit powered during operation?

It runs from an AC adaptor supplying the necessary operating voltage.

Which standards are met for safe use around electrical equipment?

It complies with DIN EN 50178, IEC 60664 and IEC 62103.

What are the available timebase settings for measurements?

The timebase ranges from 20ps/div minimum to 1000s/div maximum.
