WAGO Stepper Motor Controller, 24V dc, 2 Phase, 1.5A, Positioning Function

모든 Motor Controllers 열람하기

Subtotal (1 unit)*

₩1,102,179.00

Add to Basket
수량 선택 또는 입력
현재 액세스할 수 없는 재고 정보 - 나중에 다시 확인해 주세요.
수량
한팩당
1 +₩1,102,179.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
279-3036
Distrelec 제품 번호:
110-50-715
제조사 부품 번호:
750-671
제조업체:
WAGO
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

WAGO

Number of Phases

2

Product Type

Stepper Motor Controller

Control Function

Positioning

Output Voltage

15, 30V

Supply Voltage

24V dc

Current Rating

1.5A

Overall Length

100mm

Overall Width

12mm

Overall Depth

67.8mm

Minimum Operating Temperature

0°C

Maximum Operating Temperature

55°C

Series

70 V DC

Standards/Approvals

2015/863, EU Directives 2011/65/EU

COO (Country of Origin):
DE
The WAGO stepper controller module is an intelligent stepper controller with an on-board power driver designed to control two-phase stepper motors up to 24 V/1.5 A. The 64 times micro stepping prevents step losses due to resonance in the acceleration phases and reduces wear on the mechanical parts. Adjustable current limits for stop, acceleration and constant speed help minimize motor power dissipation.

Housing material polycarbonate and polyamide 6.6

Mounting type DIN 35 rail
