Microchip AT91SAM7X256C-AU, 32bit ARM Microcontroller, AT91, 55MHz, 256 kB Flash, 100-Pin LQFP
- RS 제품 번호:
- 177-3672P
- 제조사 부품 번호:
- AT91SAM7X256C-AU
- 제조업체:
- Microchip
가격 개당(트레이에 담겨 공급됨)**
₩17,333.60
* 배송 날짜는 선택한 수량과 배송 주소에 따라 달라질 수 있습니다.
수량 | 한팩당 |
|---|---|
| 23 - 44 | ₩17,333.60 |
| 45 + | ₩16,987.68 |
** 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 177-3672P
- 제조사 부품 번호:
- AT91SAM7X256C-AU
- 제조업체:
- Microchip
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Microchip | |
| Family Name | AT91 | |
| Package Type | LQFP | |
| Mounting Type | Surface Mount | |
| Pin Count | 100 | |
| Device Core | ARM | |
| Data Bus Width | 32bit | |
| Program Memory Size | 256 kB | |
| Maximum Frequency | 55MHz | |
| RAM Size | 64 kB | |
| USB Channels | 1 | |
| Number of PWM Units | 1 x 16 bit | |
| Number of SPI Channels | 2 | |
| Typical Operating Supply Voltage | 3.6 (Maximum) V | |
| Number of UART Channels | 2 | |
| Number of USART Channels | 2 | |
| Number of I2C Channels | 1 | |
| Number of CAN Channels | 1 | |
| Dimensions | 14 x 14 x 1.45mm | |
| Pulse Width Modulation | 1 (4 x 16 bit) | |
| Data Rate | 100Mbit/s | |
| Maximum Operating Temperature | +85 °C | |
| Number of ADC Units | 1 | |
| Length | 14mm | |
| ADCs | 8 x 10 bit | |
| Height | 1.45mm | |
| Width | 14mm | |
| Number of Ethernet Channels | 1 | |
| Instruction Set Architecture | RISC | |
| Minimum Operating Temperature | -40 °C | |
| Program Memory Type | Flash | |
| Maximum Number of Ethernet Channels | 1 | |
모두 선택 | ||
|---|---|---|
브랜드 Microchip | ||
Family Name AT91 | ||
Package Type LQFP | ||
Mounting Type Surface Mount | ||
Pin Count 100 | ||
Device Core ARM | ||
Data Bus Width 32bit | ||
Program Memory Size 256 kB | ||
Maximum Frequency 55MHz | ||
RAM Size 64 kB | ||
USB Channels 1 | ||
Number of PWM Units 1 x 16 bit | ||
Number of SPI Channels 2 | ||
Typical Operating Supply Voltage 3.6 (Maximum) V | ||
Number of UART Channels 2 | ||
Number of USART Channels 2 | ||
Number of I2C Channels 1 | ||
Number of CAN Channels 1 | ||
Dimensions 14 x 14 x 1.45mm | ||
Pulse Width Modulation 1 (4 x 16 bit) | ||
Data Rate 100Mbit/s | ||
Maximum Operating Temperature +85 °C | ||
Number of ADC Units 1 | ||
Length 14mm | ||
ADCs 8 x 10 bit | ||
Height 1.45mm | ||
Width 14mm | ||
Number of Ethernet Channels 1 | ||
Instruction Set Architecture RISC | ||
Minimum Operating Temperature -40 °C | ||
Program Memory Type Flash | ||
Maximum Number of Ethernet Channels 1 | ||
