Crouzet em4, Millenium 3 Series Touch Screen HMI - 4.3 in, TFT LCD Display, 480 x 272 pixel
- RS 제품 번호:
- 123-7009
- Distrelec 제품 번호:
- 301-05-244
- 제조사 부품 번호:
- 88970524
- 제조업체:
- Crouzet
Subtotal (1 unit)*
₩777,267.20
재고있음
- 추가로 2026년 2월 23일 부터 1 개 단위 배송
- 추가로 2026년 3월 09일 부터 1 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩777,267.20 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 123-7009
- Distrelec 제품 번호:
- 301-05-244
- 제조사 부품 번호:
- 88970524
- 제조업체:
- Crouzet
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Crouzet | |
| Series | em4, Millenium 3 | |
| Product Type | Touch Screen HMI | |
| Display Type | TFT LCD | |
| Display Resolution | 480 x 272 pixel | |
| Number of Ports | 2 | |
| Port Type | USB | |
| Minimum Operating Temperature | 0°C | |
| Backlighting | Yes | |
| Diagonal Display Size | 4.3in | |
| Maximum Operating Temperature | 40°C | |
| Standards/Approvals | CE | |
| Width | 102 mm | |
| Depth | 38.25mm | |
| Length | 128mm | |
| IP Rating | IP65 | |
| Hazardous Area Certification | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 Crouzet | ||
Series em4, Millenium 3 | ||
Product Type Touch Screen HMI | ||
Display Type TFT LCD | ||
Display Resolution 480 x 272 pixel | ||
Number of Ports 2 | ||
Port Type USB | ||
Minimum Operating Temperature 0°C | ||
Backlighting Yes | ||
Diagonal Display Size 4.3in | ||
Maximum Operating Temperature 40°C | ||
Standards/Approvals CE | ||
Width 102 mm | ||
Depth 38.25mm | ||
Length 128mm | ||
IP Rating IP65 | ||
Hazardous Area Certification No | ||
- COO (Country of Origin):
- TW
Touch Panel 4.3" TFT-LCD
Programmable touch panel for the Millenium 3 micro-PLC.
4.3’’ TFT-LCD compact resistive touch panels
65536 colors, LED backlight
Graphical resolution is 480 x 272 pixels
Wide viewing angle : 70° horizontally and vertically
Fan-less cooling system
Text, data, graphic, animation display
Processing of alarms and recipes
128 MB flash memory storage
Direct communication via the Millenium 3 programming port
Programmable with user-friendly EB
RS232/RS485 serial port
MTP6/50: USB 2.0 port for programming
MTP8/50: Ethernet port for programming and communication
Crouzet Millenium 3
The Millenium 3 is the latest generation in the Millenium series. Improvements over the Millenium 2 Plus include:
The Compact Controller has around twice the memory size
The Expandable Controller has around four times the memory size
10 bit analogue input resolution (0 – 10V signal) on dc input types (formerly 8 bit)
18 character (formerly 12), 4 line display with scrolling text and bargraph functionality
Choice of ladder or function block programming
