SMC PF2W520 Series Flow Sensor Flow Sensor for Water, 2L/min Min, 16 L/min Max
- RS 제품 번호:
- 402-848
- 제조사 부품 번호:
- PF2W520-F03N-2
- 제조업체:
- SMC
Subtotal (1 unit)*
₩869,970.00
재고있음
- 1 개 단위 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩869,970.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 402-848
- 제조사 부품 번호:
- PF2W520-F03N-2
- 제조업체:
- SMC
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | SMC | |
| Media Monitored | Water | |
| Product Type | Flow Sensor | |
| Device Type | Flow Sensor | |
| Minimum Flow Rate | 2L/min | |
| Housing Material | ABS, Polycarbonate, Thermoplastic Polyester, Nickel Plated Brass | |
| Maximum Flow Rate | 16L/min | |
| Connection Type | M12 Connector | |
| Maximum Pressure | 1.0MPa | |
| Minimum Media Temperature | 0°C | |
| IP Rating | IP65 | |
| Maximum Supply Voltage | 24V dc | |
| Maximum Media Temperature | 50°C | |
| Minimum Operating Temperature | 0°C | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | CE/UKCA, RoHS | |
| Series | PF2W520 | |
| Current Rating | 100 mA | |
| 모두 선택 | ||
|---|---|---|
브랜드 SMC | ||
Media Monitored Water | ||
Product Type Flow Sensor | ||
Device Type Flow Sensor | ||
Minimum Flow Rate 2L/min | ||
Housing Material ABS, Polycarbonate, Thermoplastic Polyester, Nickel Plated Brass | ||
Maximum Flow Rate 16L/min | ||
Connection Type M12 Connector | ||
Maximum Pressure 1.0MPa | ||
Minimum Media Temperature 0°C | ||
IP Rating IP65 | ||
Maximum Supply Voltage 24V dc | ||
Maximum Media Temperature 50°C | ||
Minimum Operating Temperature 0°C | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals CE/UKCA, RoHS | ||
Series PF2W520 | ||
Current Rating 100 mA | ||
- COO (Country of Origin):
- JP
The SMC Series PF2A Flow switch is designed for a water applications. Flow rate setting and monitoring are possible with the digital display. Integrated and remote type displays are available for different types of application. Water resistant construction is used conforming to IP65 protection. Switching from real time flow rate to accumulated flow is possible.
Digital water flow meter with remote sensor
Output for display unit with or without analogue output
