ifm electronic Flow Controller, 100 → 1000 cm³/s, Relay Output, 24 V dc, 23 mm Pipe

모든 Flow Controllers 열람하기
대량 구매 할인 기용 가능

Subtotal (1 unit)*

₩254,270.00

Add to Basket
수량 선택 또는 입력
재고있음
  • 추가로 2025년 12월 08일 부터 47 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 - 5₩254,270.00
6 +₩246,637.20

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
182-988
제조사 부품 번호:
SL5101
제조업체:
ifm electronic
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

ifm electronic

Maximum Flow Rate

100 → 1000 cm³/s

Electrical Connection

Cable

Control Output

Relay

Supply Voltage

24 V dc

Display Screen

LED

Pipe Diameter Range

23 mm

Minimum Operating Temperature

-10°C

Maximum Operating Temperature

+50°C

COO (Country of Origin):
RO

Airflow Sensor/Switch


Working on the calorimetric principle these sensors have a working range of 1 to 10m/sec (air velocity) and can be set to give an output signal should the airflow drop below the preset level.

Suitable for monitoring in HVAC applications
LED status indication of power/airflow
Insertion depth; 32mm (min), 120mm (max)
Switching point continuously adjustable
Dimensions: Length 140mm, Diameteter 23mm
Supplied with mounting clamp and installation instructions

ifm electronic Airflow Sensor/Switch


The ifm electronic airflow sensor/switch can sense a maximum flow rate of 1000cm³/s

working on the calorimetric principle. It has a supply voltage rating of 24VDC. The immersion depth into the duct can be flexibly varied via the supplied mounting clamp. This sensor has a working range of 1 to 10m/sec (air velocity) and can be set to give an output signal should the airflow drop below the preset level.

Features and Benefits


• Reliable airflow monitoring
• User-friendly setting of the requested immersion depth of the sensor
• Intuitive setting of the switch point via a potentiometer
• Signal output via potential-free relay contacts
• LED status indication of power/airflow
• Insertion depth is 32mm (minimum), 120mm (maximum)
• Switching point continuously adjustable
• Dimensions: Length is 140mm

Diameter is 23mm
• Supplied with mounting clamp and installation instructions
• Pipe diameter range is 23mm

Applications


• Ventilation systems in building automation
• Airflow monitoring in ventilation systems and/or suction operations
• Monitoring in HVAC applications

Certifications


• CE certified
• UL listed
• DIN EN 61000-6-2
• DIN EN 61000-6-3
• CRN certified
• IP65 rated
