Renesas Electronics 576 kB FIFO Memory, 28-Pin PLCC

RS 제품 번호:: 264-3516
제조사 부품 번호:: 7208L25JGI
제조업체:: Renesas Electronics

Renesas Electronics 576 kB FIFO Memory, 28-Pin PLCC

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

Subtotal (1 tube of 32 units)*

₩6,119,896.32

재고있음

32 개 단위 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당	Per Tube*
32 +	₩191,246.76	₩6,119,907.60

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 264-3516
제조사 부품 번호:: 7208L25JGI
제조업체:: Renesas Electronics

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Renesas Electronics
	Product Type	FIFO Memory
	Memory Size	576kB
	Organisation	64k x 9
	Data Bus Width	9bit
	Access Time	12ns
	Mount Type	Surface
	Package Type	PLCC
	Minimum Supply Voltage	4.5V
	Pin Count	28
	Maximum Supply Voltage	5.5V
	Bus Direction	Bi-Directional
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Height	2.79mm
	Width	11.43 mm
	Length	13.97mm
	Series	7208L
	Standards/Approvals	No
	Automotive Standard	No
	Number of Bits per Word	9
	Supply Current	120mA

	모두 선택
	브랜드 Renesas Electronics
	Product Type FIFO Memory
	Memory Size 576kB
	Organisation 64k x 9
	Data Bus Width 9bit
	Access Time 12ns
	Mount Type Surface
	Package Type PLCC
	Minimum Supply Voltage 4.5V
	Pin Count 28
	Maximum Supply Voltage 5.5V
	Bus Direction Bi-Directional
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Height 2.79mm
	Width 11.43 mm
	Length 13.97mm
	Series 7208L
	Standards/Approvals No
	Automotive Standard No
	Number of Bits per Word 9
	Supply Current 120mA

Datasheet - 7208L25JGI

COO (Country of Origin):: TW

The Renesas Electronics dual port memory buffers with internal pointers that load and empty data on a first in or first out basis. The device uses Full and empty flags to prevent data overflow and underflow and expansion logic to allow for unlimited expansion capability in both word size and depth. Data is toggled in and out of the device through the use of the write and read pins.

High speed 12 ns access time

Asynchronous and simultaneous read and write

Fully expandable in both word depth and width

Retransmit capability

High performance CMOS technology

Military product compliant to MILS TD 883

Low power consumption

Renesas Electronics 576 kB FIFO Memory, 28-Pin PLCC
