제조사부품번호

Omron A22NE Series Turn to Reset Emergency Stop Push Button, Built-In, 22 mm Cutout, 1 NO/2 NC, IP65

RS 제품 번호:: 215-1435
제조사 부품 번호:: A22NE-M-P212-N
제조업체:: Omron

Omron A22NE Series Turn to Reset Emergency Stop Push Button, Built-In, 22 mm Cutout, 1 NO/2 NC, IP65

Subtotal (1 unit)*

₩119,242.50

일시적 품절

2026년 7월 20일 부터 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩119,242.50

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 215-1435
제조사 부품 번호:: A22NE-M-P212-N
제조업체:: Omron

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Omron
	Product Type	Emergency Stop Push Button
	Mount Type	Built-In
	Cutout Diameter	22mm
	Contact Configuration	1 NO/2 NC
	Push Button Actuation	Turn to Reset
	Series	A22NE
	Illuminated	No
	IP Rating	IP65
	Colour	Red
	Terminal Type	Push-in
	Contact AC Voltage	240V
	Contact Current	10A
	Head Style	Round
	Contact DC Voltage	240V
	Head Diameter	40mm
	Standards/Approvals	No
	Hazardous Area Certification	No

	모두 선택
	브랜드 Omron
	Product Type Emergency Stop Push Button
	Mount Type Built-In
	Cutout Diameter 22mm
	Contact Configuration 1 NO/2 NC
	Push Button Actuation Turn to Reset
	Series A22NE
	Illuminated No
	IP Rating IP65
	Colour Red
	Terminal Type Push-in
	Contact AC Voltage 240V
	Contact Current 10A
	Head Style Round
	Contact DC Voltage 240V
	Head Diameter 40mm
	Standards/Approvals No
	Hazardous Area Certification No

Omron A22NE Series Emergency Stop Push Button, Red, 22mm Cutout Diameter - A22NE-M-P212-N

This emergency stop push button provides a manual safety disconnect for industrial control circuits, enabling Rapid shutdown of machinery in automation and electrical systems. Designed for front-panel mounting, it delivers a tactile, fail-safe means of stopping equipment and requires a deliberate action to restore operation.

Features & Benefits

• Red round head offers immediate Visual recognition
• Turn-to-reset actuation prevents accidental restart
• 1NO/2NC contact layout enables multiple circuit interruption
• 10A switching capacity supports moderate current loads
• IP65 ingress rating protects against dust and water jets
• Push-In Plus terminals simplify secure wiring connections

Applications

• Suitable for factory automation control panels where immediate shutdown is required
• Ideal for motor control stations requiring multi-circuit isolation
• Used with electrical distribution racks in manufacturing lines
• Can be used for machine safety stations in mechanical workshops
• Used for retrofit safety upgrades in production equipment

What mounting preparation is required for installation?

It fits a 22mm cut-out and is assembled into the panel by a built-in mount, allowing straightforward front-panel installation.

How is the device reset after activation?

The actuator uses a turn-to-reset mechanism, requiring rotation of the head to return the contacts to their normal state.

Which voltages can the contacts switch?

The contact set is rated for switching at up to 240V in both AC and DC circuits when used within the specified current limits.

How does the contact configuration support safety wiring?

The 1NO/2NC arrangement permits a normally open circuit for indication and two normally closed circuits for safety interlocks or redundant stop paths.
