Finder 48 Series Interface Relay, DIN Rail, 24V dc Coil, DPDT, 22.2mA

RS 제품 번호:: 623-7157
제조사 부품 번호:: 48.52.7.024.0050SPA
제조업체:: Finder

Finder 48 Series Interface Relay, DIN Rail, 24V dc Coil, DPDT, 22.2mA

Subtotal (1 unit)*

₩26,559.00

913 개 단위 배송 준비 완료
추가로 2026년 5월 22일 부터 700 개 단위 배송
추가로 2026년 6월 05일 부터 350 개 단위 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩26,559.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 623-7157
제조사 부품 번호:: 48.52.7.024.0050SPA
제조업체:: Finder

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Finder
	Coil Voltage	24V dc
	Product Type	Interface Relay
	Coil Resistance	1081Ω
	Contact Configuration	DPDT
	Mount Type	DIN Rail
	Series	48
	Terminal Type	Screw
	Switching Current	8A
	Switching DC Voltage	24V dc
	Coil Current	22.2mA
	Switching AC Voltage	250V ac
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	70°C
	Contact Material	Silver Alloy
	Standards/Approvals	EAC, CE
	Width	75.3mm
	Length	15.8mm
	Height	78.6mm

	모두 선택
	브랜드 Finder
	Coil Voltage 24V dc
	Product Type Interface Relay
	Coil Resistance 1081Ω
	Contact Configuration DPDT
	Mount Type DIN Rail
	Series 48
	Terminal Type Screw
	Switching Current 8A
	Switching DC Voltage 24V dc
	Coil Current 22.2mA
	Switching AC Voltage 250V ac
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 70°C
	Contact Material Silver Alloy
	Standards/Approvals EAC, CE
	Width 75.3mm
	Length 15.8mm
	Height 78.6mm

COO (Country of Origin):: IT

Finder Series 48 Interface Relay, 24V DC Coil Voltage, DPDT Contact Configuration - 48.52.7.024.0050SPA

This interface relay features a DPDT configuration, enhancing versatility for significant switching tasks. With a coil voltage of 24V DC, it is designed for diverse automation and control scenarios.

Features & Benefits

• Quick installation on standard DIN rails

• Double-pole, double-throw configuration for precise control

• Screw terminal connections ensure secure wiring

• Operates efficiently within a wide temperature range

• Silver alloy contacts enhance conductivity

• Fast activation with a turn-on time of 15ms

Applications

• Control systems for medical and dental equipment

• Building automation for efficient energy management

• Control panels for hoists and cranes

• Electrical distribution panels for enhanced safety

• Industrial machinery for process automation

How do I install it correctly on a DIN rail?

Align the relay with the rail and press firmly until it clicks into place.

What is the input current and resistance for this relay?

The input current is 22.2mA with an input resistance of 1.081kΩ.

Can it handle high temperatures in operation?

Yes, it operates effectively within a temperature range of -40 to +70°C.

What type of wire is needed for the terminal connections?

Both solid and stranded cables can be used, suitable for screw terminals.

Is it suitable for use in industrial settings?

Yes, its robust design makes it suitable for various industrial applications.

Approvals

BBJ; BEAB; CSA; DEMKO; FIMKO; GOST; IMQ; NEMKO; RINA; SEMKO; SEV; UL recognised component for Canada and US; UTE; VDE
