Finder 4C Series Interface Relay, DIN Rail Mount, 12V dc Coil, DPDT, 2-Pole

RS 제품 번호:: 154-352
제조사 부품 번호:: 4C.02.9.012.0050SPA
제조업체:: Finder

Finder 4C Series Interface Relay, DIN Rail Mount, 12V dc Coil, DPDT, 2-Pole

Subtotal (1 unit)*

₩33,708.40

재고있음

추가로 2026년 1월 26일 부터 204 개 단위 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩33,708.40

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 154-352
제조사 부품 번호:: 4C.02.9.012.0050SPA
제조업체:: Finder

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Finder
	Coil Voltage	12V dc
	Contact Configuration	DPDT
	Mounting Type	DIN Rail
	Number of Poles	2
	Series	4C Series
	Terminal Type	Screw
	Switching Voltage	250 → 440V ac
	Depth	64.6mm
	Height	82.9mm
	Length	15.8mm
	Contact Material	Silver Alloy
	Input Current	40mA
	Input Resistance	300Ω
	Maximum Operating Temperature	+70°C
	Minimum Operating Temperature	-40°C
	Turn Off Time	10ms
	Operating Temperature Range	-40 → +70°C
	Turn On Time	10ms
	Dimensions	81 x 15.8 x 64.6mm

	모두 선택
	브랜드 Finder
	Coil Voltage 12V dc
	Contact Configuration DPDT
	Mounting Type DIN Rail
	Number of Poles 2
	Series 4C Series
	Terminal Type Screw
	Switching Voltage 250 → 440V ac
	Depth 64.6mm
	Height 82.9mm
	Length 15.8mm
	Contact Material Silver Alloy
	Input Current 40mA
	Input Resistance 300Ω
	Maximum Operating Temperature +70°C
	Minimum Operating Temperature -40°C
	Turn Off Time 10ms
	Operating Temperature Range -40 → +70°C
	Turn On Time 10ms
	Dimensions 81 x 15.8 x 64.6mm

Datasheet

COO (Country of Origin):: IT

Finder 4C series Interface Relay, 12V DC Coil Voltage, DPDT Contact Configuration - 4C.02.9.012.0050SPA

This interface relay is a key component in various electrical applications. Designed for use with a DIN rail, this relay measures 81 x 15.8 x 64.6mm, featuring a double pole double throw (DPDT) configuration. Its robust build allows it to operate efficiently under a wide range of temperatures, from -40°C to +70°C.

Features & Benefits

• Compatible with both AC and DC coils for versatile use
• Ideal for controlling multiple circuits with high load ratings
• Features screw terminals for secure and reliable connections
• High switching voltage capability of 250 to 440V AC
• Input current of 40 mA ensures efficient operation
• Silver alloy contacts enhance longevity and performance

Applications

• Utilised in control panels for automation systems
• Suitable for escalators and lifts
• Effective in road and tunnel lighting systems
• Commonly used in distribution boards for electrical distribution
• Ideal for carousel warehouses and crane operations

What is the load current rating of this relay?

The load current rating is 8A/15A, providing flexibility for various applications. It can handle loads effectively, making it suitable for a range of industrial environments.

How does the relay perform in terms of switching speed?

It has a turn-on and turn-off time of approximately 10ms, allowing for quick response in automation processes, which is crucial for maintaining system efficiency.

What materials are used in the relay's contacts?

The contacts are made from silver alloy, providing excellent conductivity and resistance to wear, contributing to a mechanical life expectancy of up to 10 million cycles.

Can this relay handle high ambient temperatures?

Yes, it operates effectively at temperatures ranging from -40°C to +70°C, making it suitable for use in demanding environments.
