    Beacons

    Beacons, also known as beacon lights, are electronic devices used as signalling devices to alert people of a hazardous area or potentially dangerous situation e.g. for a fire alarm system. These visual alarm devices are extremely important in industrial and automation applications as they keep people informed of what to expect and how to respond safely.There are many different types of beacon lights and they all have a specific role to play in safety depending on their colour, light effect, and duration of signal or alarm.

    What are the meanings of the colours in the beacon lights?

    Beacons will all have a lens colour and each colour has a specific meaning. Choosing the right colour is critical. It ensures your site runs smoothly, but more importantly, allows you to keep your people safe during their working day.Red - Danger, act immediately.Amber – Be aware, a warning of a dangerous situation or condition is imminent. Requires monitoring or human intervention.Blue – A change. Usually requires a defined action by an operator such as equipment or machinery powering down.Green - Normal conditions and all is running well with no problems or issues.White - White lights are generally used for general illumination purposes and are not typically associated with specific meanings or messages.

    What are the different types of warning beacon lights?

    Beacons can be categorised into five main types:Rotating – These types of beacons have a motor-driven reflector that revolves around a bulb that is continuously lit. They produce a powerful beacon range of 360 degrees.Flashing - This type of beacon technology uses internal circuitry that cycles the bulb on and off continuously.Static – These are permanently illuminated with a steady light output once the beacon is energised.Xenon – Xenon beacons contain a discharge capacitor that operates through a converter circuit inside the beacon housing. This ignites the Xenon gas inside the tube creating a bright flash of light.LED – These types of beacons contain a semiconductor device called a light-emitting diode. The beacon will illuminate when an electric current passes through it.

    Applications that use Beacons

    Manufacturing and WarehousingMining and ConstructionOil and Gas IndustryTransportation and LogisticsPower Generation and UtilitiesChemical and Pharmaceutical Industry

    2109 표시되는 제품 Beacons

    개당
    ₩152,219.84
    AUER Signal
    -
    12 V
    Flashing, Steady
    Red
    Panel Mounted
    LED
    -
    -
    -
    -
    -
    -
    M22 Series
    -
    -
    -
    -
    -
    IP65
    • RS 제품 번호 865-5049
    • 제조사 부품 번호 M18GRYPQ
    개당
    ₩154,216.40
    Banner
    Lamp Included
    10 → 30 V dc
    -
    Green, Red, Yellow
    Panel Mount
    LED
    -
    -
    16.5mm
    -
    -
    -
    M18
    61mm
    -
    -
    -
    -
    -
    개당
    ₩703,779.88
    Pfannenberg
    -
    24 V dc
    Flashing
    Amber
    Direct Mount / Bracket Mount
    Xenon
    -
    -
    -
    -
    -
    -
    PMF 2015-SIL
    -
    -
    -
    -
    -
    IP55
    • RS 제품 번호 251-8709
    • 제조사 부품 번호 829.470.55
    개당
    ₩795,550.20
    Werma
    -
    24 V
    Continuous lighting
    Clear
    Base Mount
    LED
    -
    -
    -
    -
    -
    -
    829
    -
    -
    -
    -
    -
    -
    개당
    ₩80,764.80
    Moflash
    Lamp Included,Multifunction
    10 → 17 V ac/dc
    Flashing
    Amber
    Surface Mount
    LED
    430mA
    AC, DC
    72mm
    -
    Black
    -
    LEDS100
    107mm
    33mm
    -
    -
    -
    IP65
    개당
    ₩596,054.00
    Patlite
    -
    12 → 24 V
    Multiple Light Effects
    Green
    Indoor/Outdoor
    LED
    -
    DC
    -
    -
    Black
    -
    2M1
    13.5mm
    114.4mm
    -
    -
    -
    IP68
    개당
    ₩96,650.80
    AUER Signal
    -
    230 → 240 V
    Strobe
    Orange
    Tube Mounted
    LED
    -
    -
    -
    -
    -
    -
    ECO Series
    -
    -
    -
    -
    -
    IP66
    • RS 제품 번호 193-6823
    • 제조사 부품 번호 NE-24A-B
    개당
    ₩109,190.40
    Patlite
    -
    24 V dc
    Steady
    Blue
    Surface Mount
    LED
    26mA
    DC
    56mm
    -
    -
    -
    NE-A
    62mm
    -
    -
    -
    -
    IP65
    개당
    ₩131,148.80
    Moflash
    Lamp Included
    8 → 20 V ac/dc
    Flashing, Steady
    Amber
    Surface Mount, Wall Mount
    LED
    240mA
    AC, DC
    108mm
    -
    Black
    -
    LED TL
    104mm
    -
    -
    -
    -
    IP65
    • RS 제품 번호 190-6076
    • 제조사 부품 번호 8WD5300-1AC
    개당
    ₩99,452.00
    Siemens
    -
    12 → 230 V ac/dc
    Steady
    Green
    Bayonet Mount
    LED
    -
    AC, DC
    75mm
    5W
    -
    -
    -
    96.5mm
    -
    -
    -
    -
    IP65
    • RS 제품 번호 674-2003
    • 제조사 부품 번호 LEDD125-02-01
    개당
    ₩216,970.80
    Moflash
    Lamp Included,Multifunction
    24 V dc
    Flashing, Steady
    Amber
    Surface Mount
    LED
    150mA
    DC
    98mm
    -
    Black
    -
    LEDD125
    162mm
    -
    -
    -
    -
    IP65
    • RS 제품 번호 190-6057
    • 제조사 부품 번호 8WD5320-0CD
    개당
    ₩369,363.60
    Siemens
    Lamp Included
    24 V dc
    Flashing
    Yellow
    Bayonet Mount
    Xenon
    125mA
    DC
    75mm
    -
    -
    -
    -
    96.5mm
    -
    -
    -
    -
    IP65
    • RS 제품 번호 190-6053
    • 제조사 부품 번호 8WD5340-0CC
    개당
    ₩332,722.40
    Siemens
    Lamp Included
    115 V ac
    Flashing
    Green
    Bayonet Mount
    Xenon
    22mA
    AC
    75mm
    -
    -
    -
    -
    96.5mm
    -
    -
    -
    -
    IP65
    개당
    ₩94,449.32
    Werma
    -
    48 V
    Continuous lighting
    Clear
    Built-in Mounting
    Filament
    -
    -
    -
    -
    -
    -
    206
    -
    -
    -
    -
    -
    -
    개당
    ₩201,724.00
    AUER Signal
    -
    24-48 V ac/dc
    Flashing, Steady, Strobe
    Amber
    Horizontal, Tube Mounting, Vertical, Wall Mounting
    LED
    -
    -
    110mm
    -
    -
    -
    RCDM
    -
    -
    -
    -
    -
    IP66
    • RS 제품 번호 135-0399
    • 제조사 부품 번호 807502405
    개당
    ₩260,673.28
    AUER Signal
    -
    24 V ac/DC
    Flashing
    Red
    Surface Mount
    LED
    0.2 A @ 17 → 32 V dc, 0.22 A @ 17 → 26 V ac
    AC, DC
    120mm
    -
    Black
    -
    BLG
    102mm
    -
    -
    -
    -
    IP65
    개당
    ₩111,367.44
    AUER Signal
    -
    110 → 120 V
    Strobe
    Yellow
    Tube Mounted
    LED
    -
    -
    -
    -
    -
    -
    ECO Series
    -
    -
    -
    -
    -
    IP66
    개당
    ₩195,535.04
    AUER Signal
    -
    120 V ac
    Multi Strobe
    Yellow
    Tube Mounting
    LED
    -
    -
    -
    -
    -
    -
    T Series
    -
    -
    -
    -
    -
    IP66
    • RS 제품 번호 197-4288
    • 제조사 부품 번호 240.130.50
    개당
    ₩189,673.20
    Werma
    -
    10 → 30 V dc
    -
    Clear
    Base Mount
    LED
    80mA
    DC
    55mm
    -
    Black
    -
    MC55
    71mm
    -
    -
    -
    -
    IP65
    개당
    ₩691,151.92
    Schneider Electric
    Lamp Included,Multifunction
    48 V dc
    Flashing, Rotating
    Amber
    Base Mount
    LED
    -
    DC
    100mm
    -
    Black
    -
    Harmony XVR
    139mm
    100mm
    Yes
    Green Premium
    -
    IP23, IP65
    페이지 당 결과 수
