Telit LE910C1 IF (**WWX) 4.2V dc WiFi Module, UDP/TCP/FTP/SMTP
- RS 제품 번호:
- 285-571
- 제조사 부품 번호:
- LE910C1 IF (**WWX)
- 제조업체:
- Telit
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
현재 비가용
죄송합니다. 언제 재입고될지 모릅니다.
- RS 제품 번호:
- 285-571
- 제조사 부품 번호:
- LE910C1 IF (**WWX)
- 제조업체:
- Telit
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Telit | |
| Product Type | WiFi Module | |
| Supported Security Standards | GLONASS, BeiDou, QZSS, GPS, Galileo | |
| Data Rate | 10Mbps | |
| Output Power | 23dBm | |
| Height | 2.2mm | |
| Interface Type | USB 2.0, UART | |
| Length | 29.4mm | |
| Minimum Supply Voltage | 3.4V | |
| Maximum Supply Voltage | 4.2V dc | |
| Width | 29.4mm | |
| Minimum Operating Temperature | -40°C | |
| Supported Protocols | UDP/TCP/FTP/SMTP | |
| Maximum Operating Temperature | 85°C | |
| Series | LE910Cx | |
| Standards/Approvals | FCC /ISED, PTCRB, RED/GCF, 3GPP Release 10 | |
| 모두 선택 | ||
|---|---|---|
브랜드 Telit | ||
Product Type WiFi Module | ||
Supported Security Standards GLONASS, BeiDou, QZSS, GPS, Galileo | ||
Data Rate 10Mbps | ||
Output Power 23dBm | ||
Height 2.2mm | ||
Interface Type USB 2.0, UART | ||
Length 29.4mm | ||
Minimum Supply Voltage 3.4V | ||
Maximum Supply Voltage 4.2V dc | ||
Width 29.4mm | ||
Minimum Operating Temperature -40°C | ||
Supported Protocols UDP/TCP/FTP/SMTP | ||
Maximum Operating Temperature 85°C | ||
Series LE910Cx | ||
Standards/Approvals FCC /ISED, PTCRB, RED/GCF, 3GPP Release 10 | ||
- COO (Country of Origin):
- IT
The Telit LE910Cx series of 4G LTE modules are compliant with the 3GPP Release 10 and are available with optional quad constellation GNSS capability. This Compact LGA form factor family is available in a variety of configurations, supporting both single mode and fallback as needed for specific regions, carriers, and use
cases.
Best in class 3GPP rel10 platform
MTC features ready according to 3GPP Rel.12
Embedded GNSS solution
