OCU-440-UE390-Star EPIGAP OSA Photonics OCU-440 Series 1-LEDs UV LED 395 nm 380 mW, 2-Pin Surface package

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

모든 UV LEDs 열람하기
대량 구매 할인 기용 가능

Subtotal (1 Bag of 10 units)*

₩563,218.50

Add to Basket
수량 선택 또는 입력
현재 액세스할 수 없는 재고 정보 - 나중에 다시 확인해 주세요.

수량
한팩당
Per Bag*
10 - 10₩56,321.85₩563,218.50
20 - 30₩54,913.95₩549,139.50
40 +₩54,069.60₩540,696.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
173-6278
제조사 부품 번호:
OCU-440-UE390-Star
제조업체:
EPIGAP OSA Photonics
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

EPIGAP OSA Photonics

Number of LEDs

1

Product Type

UV LED

Peak Wavelength

395nm

Packaging

Taped in 12 mm Blister Tape

Radiant Flux

380mW

Package Type

Surface Mount

Lens Shape

Round

Number of Pins

2

LED Material

Aln Ceramic

Mount Type

Surface

Height

1mm

Length

3.8mm

Standards/Approvals

RoHS, REACH

Width

3.8mm

Automotive Standard

No

Series

OCU-440

The OCU-400 family meets the requirements of low and medium power applications. OCU-400 UV-LED are available in the wavelengths range of 350nm … 435nm. The package family OCU-440 was developed for high power applications in the range up to 1.5 W electrical power dissipation. Based on discrete power devices like the OCU-440 package or bare dices OSA Opto Light offers customized solutions in conventional or COB technology.

Size 3,0x 2,0x 1,0 mm

circuit substrate: AIO2O3 ceramics

encapsulation:silicone

Lead free solderable, soldering pads:gold plated

taped in 8 mm blister tape, cathode to transporting perforation

marking at anode

ALL Devices sorted into luminous intensity classes

taping:face-up(T)

High radiation intensity types
