Phoenix Contact Straight, Panel Female- 1 Port Type USB Type A IP67 USB Connector

모든 USB Connectors 열람하기
현재 이용 불가
이 품목의 재입고 여부는 알 수 없으며 제조업체에서 단종되고 있습니다.
RS 제품 번호:
653-6189
제조사 부품 번호:
1653744
제조업체:
Phoenix Contact
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Phoenix Contact

Product Type

USB Connector

USB Type

USB Type A

Mount Type

Panel

Connector Gender

Female

Orientation

Straight

IP Rating

IP67

Number of Ports

1

Termination Type

Screw

Minimum Operating Temperature

-40°C

Contact Material

Copper Alloy

Maximum Operating Temperature

80°C

Standards/Approvals

No

Hazardous Area Certification

No

Series

16

COO (Country of Origin):
DE

USB VARIOSUB socket


VARIOSUB connections are designed for transmitting data signals in industrial environments.

The USB coupler module is designed to be inserted in a frame. It is composed of a type A USB socket and a type B USB socket.

The frame mounting allows it to be board mounted. The seal supplied ensures sealing between the frame and the board.

Features a frame cover for board mounting to ensure sealing when the socket module is not used.

Protection index IP67.

USB - Phoenix IP67


The VARIOSUB USB range is designed for installing a USB interface on industrial machines. VARIOSUB USB connectors have a secure locking mechanism and are resistant to the impacts and vibrations frequently encountered in industrial environments. IP67 sealing is guaranteed by mechanical means.
