TDK N87 E 13/7/4 Transformer Ferrite Core, 850 nH, For Use With Miniature TransFormers, Power TransFormers
- RS 제품 번호:
- 170-1526
- 제조사 부품 번호:
- B66305G0000X187
- 제조업체:
- TDK
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
- RS 제품 번호:
- 170-1526
- 제조사 부품 번호:
- B66305G0000X187
- 제조업체:
- TDK
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | TDK | |
| Core Size | E 13/7/4 | |
| Product Type | Transformer Ferrite Core | |
| For Use With | Miniature TransFormers, Power TransFormers | |
| Core Type | Type E | |
| AL Rating | 850nH | |
| Material | N87 | |
| Maximum Operating Temperature | 155°C | |
| Series | B66305 | |
| Depth | 6.5mm | |
| Standards/Approvals | IEC 61246 | |
| Width | 3.7mm | |
| Length | 12.6mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 TDK | ||
Core Size E 13/7/4 | ||
Product Type Transformer Ferrite Core | ||
For Use With Miniature TransFormers, Power TransFormers | ||
Core Type Type E | ||
AL Rating 850nH | ||
Material N87 | ||
Maximum Operating Temperature 155°C | ||
Series B66305 | ||
Depth 6.5mm | ||
Standards/Approvals IEC 61246 | ||
Width 3.7mm | ||
Length 12.6mm | ||
- COO (Country of Origin):
- IN
EPCOS B66305 E/13/7/4 Ferrite Cores
EPCOS B66305 E13/7/4 ferrite cores For miniature transformers.E Cores have a high permeability for common mode chokes and broadband applications. The materials used in the cores N327 N87 feature a high saturation flux density and low-power loss. To IEC 61246.
