Renesas Electronics HS300x Series, Digital Output Temperature & Humidity Sensor, Surface Mount, I2C, ±1.8 %, 6-Pin LGA
- RS 제품 번호:
- 217-3749
- 제조사 부품 번호:
- HS3002
- 제조업체:
- Renesas Electronics
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
대량 구매 할인 기용 가능
Subtotal (1 tape of 100 units)*
₩409,500.00
마지막 RS 재고
- 최종적인 3,400 개 unit(s)이 배송 준비 됨
수량 | 한팩당 | Per Tape* |
|---|---|---|
| 100 - 100 | ₩4,095.00 | ₩409,597.50 |
| 200 - 300 | ₩4,015.05 | ₩401,427.00 |
| 400 + | ₩3,933.15 | ₩393,393.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 217-3749
- 제조사 부품 번호:
- HS3002
- 제조업체:
- Renesas Electronics
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Renesas Electronics | |
| Product Type | Temperature & Humidity Sensor | |
| Output Type | Digital | |
| Interface Type | I2C | |
| Sub Type | Temperature & Humidity Sensor | |
| Accuracy | ±1.8 % | |
| Mount Type | Surface | |
| Pin Count | 6 | |
| Maximum Operating Temperature | 125°C | |
| Minimum Operating Temperature | -40°C | |
| Minimum Supply Voltage | 2.3V | |
| Maximum Supply Voltage | 5.5V | |
| Package Type | LGA | |
| Height | 2.41mm | |
| Length | 3mm | |
| Standards/Approvals | No | |
| Series | HS300x | |
| Automotive Standard | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 Renesas Electronics | ||
Product Type Temperature & Humidity Sensor | ||
Output Type Digital | ||
Interface Type I2C | ||
Sub Type Temperature & Humidity Sensor | ||
Accuracy ±1.8 % | ||
Mount Type Surface | ||
Pin Count 6 | ||
Maximum Operating Temperature 125°C | ||
Minimum Operating Temperature -40°C | ||
Minimum Supply Voltage 2.3V | ||
Maximum Supply Voltage 5.5V | ||
Package Type LGA | ||
Height 2.41mm | ||
Length 3mm | ||
Standards/Approvals No | ||
Series HS300x | ||
Automotive Standard No | ||
The Renesas Electronics HS3002 series sensor is a highly-accurate, fully-calibrated relative humidity and temperature sensor. It has high accuracy, fast measurement response time, and long-term stability, along with the small package size. It has 6 lead count and has LGA package type.
Temperature sensor accuracy: ±0.2°C typical
14-bit resolution: 0.01% RH
Low power consumption 1.0μA average
2.3V to 5.5V extended supply voltage
