제조사부품번호

Microchip EMC1825T Series, Digital, Analogue Output Temperature & Humidity Sensor, Surface Mount, I2C, 2 Wire, SMBus,

RS 제품 번호:: 187-1569
제조사 부품 번호:: EMC1825T-1E/9R
제조업체:: Microchip

Microchip EMC1825T Series, Digital, Analogue Output Temperature & Humidity Sensor, Surface Mount, I2C, 2 Wire, SMBus,

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

대량 구매 할인 기용 가능

Subtotal (1 reel of 3000 units)*

₩5,662,560.00

일시적 품절

2026년 5월 04일 부터 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당	릴당*
3000 - 12000	₩1,887.52	₩5,663,124.00
15000 +	₩1,849.92	₩5,549,760.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 187-1569
제조사 부품 번호:: EMC1825T-1E/9R
제조업체:: Microchip

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Microchip
	Product Type	Temperature & Humidity Sensor
	Output Type	Digital, Analogue
	Sub Type	Temperature Sensor
	Interface Type	I2C, 2 Wire, SMBus
	Mount Type	Surface
	Pin Count	10
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	125°C
	Minimum Supply Voltage	1.62V
	Maximum Supply Voltage	3.6V
	Package Type	VDFN
	Series	EMC1825T
	Height	2mm
	Length	2.5mm
	Width	0.85 mm
	Standards/Approvals	No
	Automotive Standard	No

	모두 선택
	브랜드 Microchip
	Product Type Temperature & Humidity Sensor
	Output Type Digital, Analogue
	Sub Type Temperature Sensor
	Interface Type I2C, 2 Wire, SMBus
	Mount Type Surface
	Pin Count 10
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 125°C
	Minimum Supply Voltage 1.62V
	Maximum Supply Voltage 3.6V
	Package Type VDFN
	Series EMC1825T
	Height 2mm
	Length 2.5mm
	Width 0.85 mm
	Standards/Approvals No
	Automotive Standard No

Datasheet EMC1825T-1E/9R

The Microchip EMC1825 is a 5 channel temperature sensor features Rate of Change (ROC), Resistance Error Correction (REC), Beta Compensation (to support CPU diodes requiring the BJT/transistor model), and Ideality Configuration combine to provide a robust solution for complex environmental monitoring applications. This 2-Wire (I2C compatible),high accuracy sensor a pre-emptive system alert and another protective measurement layer to catch and manage variable system temperatures. It operates on voltage range of 1.62V to 3.6V.

Temperature sensor resolution (Internal/External) of 0.125°C

Configurable alert pins

1001_100(r/w) SMBus address

Auto-Beta Compensation, Configurable Ideality Factor, Hottest Diode Compare, Resistance Error Correction

Extended temperature range between -40°C and +125°C

10-Lead Very Thin Plastic Dual Flat, No Lead – 2.5 x 2.0 mm Body (VDFN) package

Microchip EMC1825T Series, Digital, Analogue Output Temperature & Humidity Sensor, Surface Mount, I2C, 2 Wire, SMBus,
