STMicroelectronics STLM20 Series, Voltage Output Temperature Sensor, Surface Mount, Analogue, ±1.5°C, 5-Pin SOT-323
- RS 제품 번호:
- 578-825
- 제조사 부품 번호:
- STLM20W87F
- 제조업체:
- STMicroelectronics
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
Subtotal (1 pack of 5 units)*
₩5,031.00
재고있음
- 5 개 단위 배송 준비 완료
- 추가로 2026년 5월 06일 부터 2,640 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 | 한팩당* |
|---|---|---|
| 5 + | ₩1,006.20 | ₩5,031.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 578-825
- 제조사 부품 번호:
- STLM20W87F
- 제조업체:
- STMicroelectronics
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | STMicroelectronics | |
| Product Type | Temperature Sensor | |
| Output Type | Voltage | |
| Interface Type | Analogue | |
| Sub Type | Temperature Sensor | |
| Accuracy | ±1.5°C | |
| Mount Type | Surface | |
| Pin Count | 5 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 130°C | |
| Minimum Supply Voltage | 2.4V | |
| Maximum Supply Voltage | 5.5V | |
| Package Type | SOT-323 | |
| Height | 1mm | |
| Series | STLM20 | |
| Standards/Approvals | No | |
| Length | 2.2mm | |
| Sensor Gain | -11.77mV/°C | |
| Automotive Standard | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 STMicroelectronics | ||
Product Type Temperature Sensor | ||
Output Type Voltage | ||
Interface Type Analogue | ||
Sub Type Temperature Sensor | ||
Accuracy ±1.5°C | ||
Mount Type Surface | ||
Pin Count 5 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 130°C | ||
Minimum Supply Voltage 2.4V | ||
Maximum Supply Voltage 5.5V | ||
Package Type SOT-323 | ||
Height 1mm | ||
Series STLM20 | ||
Standards/Approvals No | ||
Length 2.2mm | ||
Sensor Gain -11.77mV/°C | ||
Automotive Standard No | ||
STLM20 Analogue Temperature Sensors
The STLM20 analogue temperature sensors have been designed for low power applications such as portable devices (smartphones, GPS, PDA devices and medical instruments) and monitors for RF power transistors and voltage-controlled crystal oscillators.
Features;
Low power
2.4 V to 5.5 V operating voltage range
-55°C to +130°C (grade 7) -40°C to +85°C (grade 9) temperature range
Temperature & Humidity Sensors, STMicroelectronics
