Jumo 703051 DIN Rail Temperature Control Module 2 Input, 2 Output Digital 24V ac/dc Controller

RS 제품 번호:: 467-000
제조사 부품 번호:: 703051/8-00-00-00-00-00-00-42/000
제조업체:: Jumo

Jumo 703051 DIN Rail Temperature Control Module 2 Input, 2 Output Digital 24V ac/dc Controller

Subtotal (1 unit)*

₩952,142.92

현재 액세스할 수 없는 재고 정보 - 나중에 다시 확인해 주세요.

수량	한팩당
1 +	₩952,142.92

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 467-000
제조사 부품 번호:: 703051/8-00-00-00-00-00-00-42/000
제조업체:: Jumo

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Jumo
	Product Type	Temperature Control Module
	Output Type	Digital
	Number of Inputs	2
	Number of Outputs	2
	Maximum Current	8A
	Maximum Operating Temperature	55°C
	Minimum Operating Temperature	-10°C
	Terminal Type	Spring Cage Terminal
	Control Type	Controller
	Maximum Supply Voltage	24V ac/dc
	Digital Comms	Ethernet/Modbus TCP, Profinet Interface, RS485 Modbus RTU
	Diagnostics	Yes
	Display Type	18 Segment LCD, LCD - Dot Matrix
	Maximum Voltage	230V ac
	Length	114.9mm
	Standards/Approvals	ASTM E1751M-15, NAMUR NE 43, IEC 60751:2008, IEC 60584-1:2013, GOST R 8.585-2001, GOST 6651-2009 A.2, DIN EN 60751:2009, DIN EN 60584-1:2014, DIN 43710
	IP Rating	IP65
	Width	48mm
	Series	703051
	Mount Type	DIN Rail
	Input Type	Thermocouple, Voltage, Analogue, Current, Digital, Potentiometer

	모두 선택
	브랜드 Jumo
	Product Type Temperature Control Module
	Output Type Digital
	Number of Inputs 2
	Number of Outputs 2
	Maximum Current 8A
	Maximum Operating Temperature 55°C
	Minimum Operating Temperature -10°C
	Terminal Type Spring Cage Terminal
	Control Type Controller
	Maximum Supply Voltage 24V ac/dc
	Digital Comms Ethernet/Modbus TCP, Profinet Interface, RS485 Modbus RTU
	Diagnostics Yes
	Display Type 18 Segment LCD, LCD - Dot Matrix
	Maximum Voltage 230V ac
	Length 114.9mm
	Standards/Approvals ASTM E1751M-15, NAMUR NE 43, IEC 60751:2008, IEC 60584-1:2013, GOST R 8.585-2001, GOST 6651-2009 A.2, DIN EN 60751:2009, DIN EN 60584-1:2014, DIN 43710
	IP Rating IP65
	Width 48mm
	Series 703051
	Mount Type DIN Rail
	Input Type Thermocouple, Voltage, Analogue, Current, Digital, Potentiometer

COO (Country of Origin):: DE

The Jumo meroTRON Controller includes additional relays, higher output capacities, and extended communication options. It supports options like a startup ramp for hot runner technology and a boost function for enhanced performance. It supports Ethernet, PROFINET and RS485 interface.

Customizable menu structure

IP65 protection

USB host interface

Data logger

Jumo 703051 DIN Rail Temperature Control Module 2 Input, 2 Output Digital 24V ac/dc Controller
