Gefran GRM-H DIN Rail Power Controller, 118 x 35mm 2 Input, 2 Output PNP, 30 V dc Supply Voltage ON/OFF

모든 Temperature Controllers 열람하기

Subtotal (1 unit)*

₩669,184.12

Add to Basket
수량 선택 또는 입력
재고있음
  • 추가로 2025년 12월 08일 부터 2 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 +₩669,184.12

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
199-997
제조사 부품 번호:
GRM-H-25-48-AN-OL-0-0-0-0-0
제조업체:
Gefran
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Gefran

Output Type

PNP

Supply Voltage

30 V dc

Size

118 x 35mm

Number of Inputs

2

Number of Outputs

2

Control Type

ON/OFF

Mounting Type

DIN Rail

Series

GRM-H

COO (Country of Origin):
IT
The Gefran Compact Power Controllers with Analog Control, IO Link Communication, and Modbus RTU are designed to manage complex electrical loads, such as infrared lamps and Silicon Carbide heating elements, that do not maintain constant current absorption during operation. These types of loads can draw currents up to 15 times higher than their rated value during startup when cold. To prevent breakdowns or downtime, the GRM controllers continuously monitor the absorption current and use specialized algorithms to limit the inrush current, ensuring the system reaches optimal operating conditions safely and efficiently.

Connectors for push in control signals
Configuration and diagnostics via smartphone app with NFC technology
Alarm threshold calibration by digital input
Internal over voltage protection
