제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	XP Power
	Output Voltage	3.3V dc
	Output Current	1A
	Input Voltage	4.75 → 36V dc
	Mounting Type	Surface Mount
	Number of Outputs	1
	Package	SMD
	Power Rating	1W
	Efficiency	94%
	Ripple And Noise	75mV Pk-Pk
	Maximum Temperature	+105°C
	Minimum Temperature	-40°C
	Series	STS10
	Line Regulation	±0.2%
	Load Regulation	±0.6%
	Width	11.8mm
	Maximum Input Current	900mA
	MTBF	3.5 (Minimum)Mh
	Power Signal Conversion Type	DC-DC
	Length	15.2mm
	Protection Features	Short Circuit Protection
	Weight	1.4g
	Depth	3.6mm

	모두 선택
	브랜드 XP Power
	Output Voltage 3.3V dc
	Output Current 1A
	Input Voltage 4.75 → 36V dc
	Mounting Type Surface Mount
	Number of Outputs 1
	Package SMD
	Power Rating 1W
	Efficiency 94%
	Ripple And Noise 75mV Pk-Pk
	Maximum Temperature +105°C
	Minimum Temperature -40°C
	Series STS10
	Line Regulation ±0.2%
	Load Regulation ±0.6%
	Width 11.8mm
	Maximum Input Current 900mA
	MTBF 3.5 (Minimum)Mh
	Power Signal Conversion Type DC-DC
	Length 15.2mm
	Protection Features Short Circuit Protection
	Weight 1.4g
	Depth 3.6mm

Datasheet

COO (Country of Origin):: CN

The STS10 is a new series of innovative low cost DC-DC buck regulators. Based on SMD technology and high levels of automation the series offers many features including voltage trimming, remote on/off, continuous short circuit protection, regulation and high efficiency.

Regulated single outputs from 1.2 to 15 VDC
Wide input range
SMD-10 package
Non-isolated
Output voltage trim ±10%
High efficiency up to 96%
Class B conducted & radiated emissions with external components
Short-circuit protection
No heatsink required
Remote On/Off
Tape & reel package available
Short-circuit protection
Full load to +65°C
3 Year Warranty

XP Power Switching Regulator, Surface Mount, 3.3V dc Output Voltage, 4.75 → 36V dc Input Voltage, 1A Output
