Werma 644 Series Yellow Flashing Effect Beacon Unit, 24 V dc, LED Bulb, DC, IP65
- RS 제품 번호:
- 481-939
- 제조사 부품 번호:
- 644.320.55
- 제조업체:
- Werma
대량 구매 할인 기용 가능
가격 개당**
₩189,534.08
7 재고있음 5-9영업일내 홍콩 발송*
* 배송 날짜는 선택한 수량과 배송 주소에 따라 달라질 수 있습니다.
재고 확인하기
수량 | 한팩당 |
---|---|
1 - 5 | ₩189,534.08 |
6 + | ₩181,698.24 |
** 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 481-939
- 제조사 부품 번호:
- 644.320.55
- 제조업체:
- Werma
- COO (Country of Origin):
- DE
Stacking Signal Tower - KombiSIGN 71, 70 mm, IP65
The WERMA KombiSIGN 71 modular stacking signal tower is an ideal solution to the increasing requirement for safety, machine productivity and reduced downtime. The modular design of these stacking towers enables quick and easy installation. Each KombiSIGN module is equipped with a bayonet fixing with integral contact system. Simply align the corresponding white marks and gently twist to lock them in place.
Features and Benefits
• Suitable for machine and manual Andon indication
• Modular system allows a completely free combination of optical and audible signal elements
• Mechanical and electrical connection of the elements in the space of seconds using a bayonet connection system
• Completely safe element changes (contact-voltage proof) without the need for tools
• Protection rating IP65 for use in extreme conditions
• Up to 5 elements can be mounted on a terminal base
• Flexible combination of optical and audible elements
• Optical isolation due to O-ring seal stopping illumination of adjacent element
• Operating voltage for the continuous incandescent element is dependant on bulb fitted
• LED EVS elements have an extremely bright, random sequence of light to immediately grab attention
• Ultra-bright elements are up to 20 times brighter than conventional LED beacons. Intelligent electronics ensure operation at maximum brightness
• Vocal element plays customer specific audio files in mp3 format (sounds, alarms, music or spoken word)
• Optional self adjusting siren automatically adjusts output between 80 & 100 dB depending on ambient sound levels
• AS-Interface element can be easily connected to the networking system which considerably reduces complex wiring
• Improved connection with cage clamp technology
• Operating temperature range is -20 to +50 °C
• Polyamide body with polycarbonate lenses, 70 mm diameter
• Modular system allows a completely free combination of optical and audible signal elements
• Mechanical and electrical connection of the elements in the space of seconds using a bayonet connection system
• Completely safe element changes (contact-voltage proof) without the need for tools
• Protection rating IP65 for use in extreme conditions
• Up to 5 elements can be mounted on a terminal base
• Flexible combination of optical and audible elements
• Optical isolation due to O-ring seal stopping illumination of adjacent element
• Operating voltage for the continuous incandescent element is dependant on bulb fitted
• LED EVS elements have an extremely bright, random sequence of light to immediately grab attention
• Ultra-bright elements are up to 20 times brighter than conventional LED beacons. Intelligent electronics ensure operation at maximum brightness
• Vocal element plays customer specific audio files in mp3 format (sounds, alarms, music or spoken word)
• Optional self adjusting siren automatically adjusts output between 80 & 100 dB depending on ambient sound levels
• AS-Interface element can be easily connected to the networking system which considerably reduces complex wiring
• Improved connection with cage clamp technology
• Operating temperature range is -20 to +50 °C
• Polyamide body with polycarbonate lenses, 70 mm diameter
Permanent Multi-colour LED Light Element
• Seven colours in one beacon
• Different colours can be triggered via the pins in the terminal element
• Positive and negative control logic
• The three basic colours (red/yellow/green) can be triggered using only two PLC outputs
• High light intensity
• Different colours can be triggered via the pins in the terminal element
• Positive and negative control logic
• The three basic colours (red/yellow/green) can be triggered using only two PLC outputs
• High light intensity
Note
Lamps are not supplied and must be purchased separately. Not compatible with KombiSIGN 70.
Approvals
UL listed, CSA, VDE

WERMA Beacon Unit, Yellow Lens Colour, Flashing Light Effect - KombiSIGN 71 Series - 644.320.55
Use this WERMA yellow beacon unit to signal machine faults in your industrial applications. You can stack it with other beacon units from the KombiSIGN 71 series to assemble a complete signal tower. This device has an LED bulb that's highly visible in most lighting conditions. Its flashing light effect means it easily attracts attention in busy environments.
Features & Benefits
• Low current consumption of 35mA for energy-efficient operation
• Compact dimensions of 66 (height) x 70mm (diameter) for installation in tight spaces
• Wide operating temperature range of -20°C to +50°C for use in demanding conditions
• IP65 rating indicates protection against dust and low-pressure water jets
• Compact dimensions of 66 (height) x 70mm (diameter) for installation in tight spaces
• Wide operating temperature range of -20°C to +50°C for use in demanding conditions
• IP65 rating indicates protection against dust and low-pressure water jets
Applications
• Process and control systems
• Construction sites
• Warehouses
• Food production
• Construction sites
• Warehouses
• Food production
How long will this beacon unit last?
This beacon unit has a long service life of up to 50,000 hours, so it won't need frequent replacement.
속성 | 값 |
---|---|
Range | KombiSIGN 71 |
Series | 644 |
Component Type | Beacon |
Current Type | DC |
Light Effect | Flashing |
Lens Colour | Yellow |
Bulb Type | LED |
Supply Voltage | 24 V dc |
Height | 65mm |
IP Rating | IP65 |
Base Diameter | 70mm |
Maximum Temperature | +50°C |
Minimum Temperature | -20°C |
